Output module NX-507E or NX-508E
Output module DIP 1 DIP 2 DIP 3 Expander number
reported
1 ON ON OFF 24
2 OFF OFF ON 25
3 ON OFF ON 26
4 OFF ON ON 27
5 ON ON ON 28
6 OFF OFF OFF 29
7 ON OFF OFF 30
8 OFF ON OFF 31
Hardwired expander NX-216
Starting zone number DIP 1 DIP 2 DIP 3 Expander number reported
Zone 9 ON OFF OFF 23
Zone 17 OFF ON OFF 16
Zone 25 ON ON OFF 17
Zone 33 OFF OFF ON 18
Zone 41 ON OFF ON 19
NX-8-EUR Installation manual Page 111 02/07/06
