CHARACTER DATA: Character data is used to enter LCD text when programming (see [*]-[9]-
[2] feature for custom messages). Custom zone descriptions and messages are stored using
character or ASCII data types. This information is programmed using the bottom line of the
display as a text editor. Once a character location has been entered, the current data will be
displayed on the bottom line. As always, the top line will display the current location and
segment number. The five (5) function keys, as well as the ‘up’ and ‘down’ arrows to the right
of the display, are now used to edit the message before saving it back to the location storage.
An underscore (_) in the display indicates the current cursor location. To move the cursor to
the right, press the [*] key. To move the cursor to the left, press the [Cancel] key. To change
the character at the current cursor location, press the Up or Down Arrow until the desired
character is displayed. To accept this character, press the [*] key. The character will remain,
and the cursor will advance one space to the right.
You can also immediately select a character from the underlying table. By doing this you can
quickly form a word without having to scroll down all characters in the list
Follow the procedure below to select a character:
Step 1 Enter the double figured number of the wanted character of the table
below.
Step 2 Confirm the character by pressing the [*] key.
Step 3 Repeat steps 1 and 2 until the complete word is formed.
Step 4 Confirm the word by pressing the [#] key.
Key Function
[Stay]
Inserting spaces
[Chime]
Deleting characters
[Exit]
Access the library
[Bypass]
Make a character or entire word flashing
[Cancel]
Backspace
[*]
Confirm the word or character being displayed
[#]
Finished editing the line
NX-148 LIBRARY
ALARM DURESS INSTANT PIR STORAGE
AREA EAST INTERIOR PORCH STUDY
AUDIO EMERGENCY JUNK ROOM TAMPER
BACK EXIT KITCHEN RUMPUS TELEVISION
BATHROOM EXTERIOR LIBRARY SAFE TROUBLE
BEAM FIRE LIGHT SENSOR TV
BEDROOM FRONT LIVING SHOCK UP
BUTTON GAME MASTER SHOP UTILITY
CEILING GARAGE MICROWAVE SIDE VAULT
CLOSET GLASSBREAK MOTION SKYLIGHT WAREHOUSE
DELAY GUEST NORTH SLIDING WEST
DEN HALL NURSERY SMALL WINDOW
DETECTOR HEAT OFFICE SMOKE WING
DINING HOLDUP PANIC SOUND WIRELESS
DOOR HOUSE PANTRY SOUTH YARD
DOWN INFRARED PHONE STAIRS ZONE
NX-8-EUR Installation manual Page 31 02/07/06
