GE NX-1308E - Caddx 8 Zone LED Keypad User Manual

NX-8 Control
43
LOC PG DESCRIPTION DEFAULT DATA
L
37 23
Segment #3 (Circle numbers to program)
1
2
3
4
5
6
7
8
Box Tamper report enabled.
AC Fail report enabled.
Low Battery report enabled.
Auxiliary power over current report enabled.
Siren supervision report enabled.
Telephone Line Cut report enabled.
Ground Fault Detection report enabled.
Expander trouble report enabled.
Segment #4 (Circle numbers to program)
1
2
3
4
5
6
7
8
Failure To Communicate report enabled.
Log Full report enabled.
Autotest report enabled.
Start and End Programming report enabled.
End Download report enabled.
Sensor Low Battery report enabled.
Sensor Missing report enabled.
Reserved.
Segment #5 (Circle numbers to program)
1
2
3
4
5
6
7
8
Lost Clock service LED enable.
Zone Doubling enable.
Disable on-board eight zones.
Enables two trips on the same cross-zone to activate the alarm.
Disables bypass reports for force armed zones
Reserved.
Clock uses internal crystal.
Disable Temporal Siren on Fire (Do not disable on UL listed systems)
L
38 23 SWINGER SHUTDOWN COUNT 1 _
KEYPAD SOUNDER CONTROL
Segment #1 (Circle numbers to program)
L
39 23
1
2
3
4
5
6
7
8
Keypad sounds for Telephone Line Cut when in the Armed state.
Keypad sounds for Telephone Line Cut when in the Disarmed state.
Keypad sounds upon AC Power Failure.
Keypad sounds upon Low Battery Detection.
Keypad sounds during Cross Zone Trip Time.
Keypad sounds for Tamper Alarm.
Reserved.
Keypad sounds for expander trouble (required for UL).
SYSTEM TIMERS
Segment #1 Dynamic Battery Test duration (0-255 minutes)
0 _
Segment #2 AC Failure report delay (0-255 minutes)
5 _
Segment #3 Power Up Delay (0-60 seconds)
60 _
Segment #4 Siren Time (1-254 minutes)
8 _
Segment #5 Telephone Line Cut delay (0-255 seconds)
0 _
Segment #6 Cross Zone Time (0-255 minutes)
5 _
Segment #7 Chime Time in 50 mS increments (0-255)
3 _
Segment #8 Dialer delay (15-255 seconds)
30 _
Segment #9 Fire Alarm Verification Time (120-255 sec.)
0 _
L
40 24
Segment #10 Listen-In Time (0-255 seconds)
0 _

GE NX-1308E - Caddx 8 Zone LED Keypad Specifications

Power

operating power	16.5 VAC 25, 40, or 50 VA Transformer
auxiliary power with 25 VA transformer	12 VDC Regulated 500 mA
auxiliary power with 40 or 50 VA transformer	12 VDC Regulated 1 AMP
auxiliary power with NX-320E power supply	12 VDC Regulated 2 AMPS
LED keypad current draw	130 mA max.
LED keypad zones normal w/o sounder	55 mA
NX-148E LCD keypad current draw	110 mA max.
NX-148E LCD keypad w/o sounder	75 mA

Operating Environment

operating temperature	32 to 120 degrees F

Loop Specifications

standard loop resistance	300 Ohms Maximum
2-wire smokes resistance	30 Ohms Maximum
loop response	Selectable 50mS or 500mS

Weight and Dimensions

LED keypad width	6.4"
LED keypad height	4.0"
LED keypad depth	1.1"
NX-148E LCD keypad width	6.4"
NX-148E LCD keypad height	5.3"
NX-148E LCD keypad depth	1.0"
metal enclosure width	11.25"
metal enclosure height	11.25"
metal enclosure depth	3.50"
shipping weight	9 lbs.
