GE NX-1308E - Caddx 8 Zone LED Keypad User Manual

NX-8 Control
44
LOC PG DESCRIPTION DEFAULT DATA
SPECIAL FEATURES
Segment #1 (Circle numbers to program)
41 24
1
2
3
4
5
6
7
8
Enables six digit code option. All arm/disarm/Go To Program codes require six digits
Requires valid user code entry for [r]-[9]-[8] and [r]-[9]-[9] functions to work.
Enable Auto Cancel / Abort.
Enable Walk-Test Mode.
Reserved.
Reserved.
Reserved.
Reserved.
L
42 24 GO TO PROGRAM CODE 9-7-1-3-0-0 _ _ _ _ _ _
GO TO PROGRAM CODE PARTITION AND AUTHORIZATION
Segment #1 (Circle numbers to program)
1
2
3
4
5
6
7
8
Reserved.
Enables "Go To Program Code" as an arm only code.
Enables "Go To Program Code" as an arm only after closing.
Enables "Go To Program Code" as a master arm/disarm code (can change user codes)
Enables "Go To Program Code" as an arm/disarm code.
Enables "Go To Program Code" to bypass zones.
Enables "Go To Program Code" opening and closing reports.
Reserved.
Segment #2 (Circle numbers to program)
43 24
1
2
3
4
5
6
7
8
Enables "Go To Program Code" for partition #1.
Enables "Go To Program Code" for partition #2.
Enables "Go To Program Code" for partition #3.
Enables "Go To Program Code" for partition #4.
Enables "Go To Program Code" for partition #5.
Enables "Go To Program Code" for partition #6.
Enables "Go To Program Code" for partition #7.
Enables "Go To Program Code" for partition #8.
L
44
25 DURESS CODE
15-15-15-15-15-15 _ _ _ _ _ _
AUXILIARY OUTPUTS 1-4 PARTITION SELECTION
Segments 1 2 3 4
45
25
Partition #1
Partition #2
Partition #3
Partition #4
Partition #5
Partition #6
Partition #7
Partition #8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
46 25 AUXILIARY OUTPUTS 1-4 SPECIAL TIMING
Segments 1 2 3 4
Auxiliary output timed in minutes.
Auxiliary output to latch.
Auxiliary output to stop timing upon user code entry.
Auxiliary output to activate only between closing and opening time.
Auxiliary output to activate only between opening and closing time.
Invert auxiliary output ( 0 volts going to 12 volts when activated).
Reserved
Reserved
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8

GE NX-1308E - Caddx 8 Zone LED Keypad Specifications

Power

operating power	16.5 VAC 25, 40, or 50 VA Transformer
auxiliary power with 25 VA transformer	12 VDC Regulated 500 mA
auxiliary power with 40 or 50 VA transformer	12 VDC Regulated 1 AMP
auxiliary power with NX-320E power supply	12 VDC Regulated 2 AMPS
LED keypad current draw	130 mA max.
LED keypad zones normal w/o sounder	55 mA
NX-148E LCD keypad current draw	110 mA max.
NX-148E LCD keypad w/o sounder	75 mA

Operating Environment

operating temperature	32 to 120 degrees F

Loop Specifications

standard loop resistance	300 Ohms Maximum
2-wire smokes resistance	30 Ohms Maximum
loop response	Selectable 50mS or 500mS

Weight and Dimensions

LED keypad width	6.4"
LED keypad height	4.0"
LED keypad depth	1.1"
NX-148E LCD keypad width	6.4"
NX-148E LCD keypad height	5.3"
NX-148E LCD keypad depth	1.0"
metal enclosure width	11.25"
metal enclosure height	11.25"
metal enclosure depth	3.50"
shipping weight	9 lbs.
