Appendix C: Messages On Display
Optima XR220amx X-Ray System 54400222-1EN Rev 1 DRAFT 11092010 C-1
Operator Manual © 2010 General Electric Company. All rights reserved.
Appendix C: Messages On Display
Two kinds of messages can appear on the message display on the control cover: status messages and
error messages.
Status messages simply inform you of the operating condition of the Definium AMX 700, and look
something like this.
Figure C-1 Ready message
Another type of message, called an error message, may appear should a problem occur with the
equipment. An error message looks something like this.
Figure C-2 Error message
Note that an error message includes an alphanumeric code, and will display one line at a time.
If an error message appears, follow these steps.
1. Try the function again. If the problem is corrected, and no error message is displayed, proceed as
usual.
2. If the error message still displays, turn the unit OFF then back ON.
Diagnostics or self-tests are quickly performed when the unit is turned back on.
When diagnostics are complete, the following message displays:
ERROR XXX
OCCURRED WHEN
THE UNIT WAS
LAST OPERATED –
PROCEED WITH
---CAUTION –
3. Now try the function once more. If the problem is corrected, and no error message is displayed,
proceed as usual.
4. If the problem persists, call your service representative, and report the code and message shown on
the display. This will prepare service for the type of problem encountered and the service required.
Table
C-1 lists the status messages and provides a brief explanation of each one.
