7 Protection Parameter Settings
2 PROTECTION PARAMETER SETTINGS
2.1 System Data
Sr. No Parameter Defaults setting Setting/Ranges
1. Language English Not editable
2. Description P50 Agile P253 Not editable
3. Model Number P253xxxAxA0010A Not editable
4. Serial Number xxxP253xxxx Not editable
This cell sets the frequency to either 50 Hz or 60 Hz.
7. USB Address 1 Not editable
This cell displays the address for the front USB port of the relay.
This cell displays the parity format used in the data frames.
This cell displays the communication speed between relay and configuration tool.
10. Password 0000 0000 to zzzz
This cell allows you to set new password. (Alphanumeric 4- characters)
This setting displays the active setting group (Group1/Group2, whichever is selected).
12.
Opto I/P Status Status of the Inputs Not editable
This setting displays the current status of Digital input
13.
Relay O/P Status Status of the outputs Not editable
This setting displays the current status of Digital output
No Operation / Open / Close
This setting supports open and close commands if enabled in the Circuit Breaker Control menu
15. Opto I/P DC DC/AC
This setting allows selection of auxiliary voltage type AC/DC for opto inputs.
16. Config Port USB USB/RP
This setting allows selection of communication port for relay configuration using P50 Agile configurator.
(For DNP3.0, Config Port setting is fixed as ‘USB’)
2.2 CB CONTROL Settings
This setting specifies to enter the set password
2. TCS Alarm No Yes/No
This setting is used to enable (activate) or disable (turn off) the Trip Circuit Supervision alarm function
3. TCS Timer 5.00 S 0.1s to 10s step 0.01s
This setting is used to set the time delay for the Trip Circuit supervision. If relay detects any discontinuity, then TCS alarm is generated
after the set time delay.
4. CB Open S'vision Enabled Enabled/Disabled
This setting is used to enable (activate) or disable (turn off) the CB Open Supervision function
