2.8 IO CONFIGURATION Settings
Sr. No Parameter Defaults setting Setting/Ranges
1. Password 0000 0000 to zzzz
This setting specifies to enter the set password
2.
Relay
Gen Strt*
654321
000000
6ïƒ RL6……..1ïƒ RL1
1 = assigned ; 0 = not assigned
This cell sets the output contact RL1 – RL6 for desired function.
3.
LED G
Gen Strt*
8765
0000
8ïƒ LED8……..5ïƒ LED5
1 = assigned ; 0 = not assigned
This cell sets the Green LED L5 – L8 for desired function.
4.
LED R
Gen Strt*
8765
0000
8ïƒ LED L8…..5ïƒ LED L5
1 = assigned ; 0 = not assigned
This cell sets the RED LED L5 – L8 for desired function.
5.
AND Logic
Gen Strt*
DCBA
0000
Dïƒ AND Logic D……..Aïƒ AND Logic A
1 = assigned ; 0 = not assigned
This cell sets the input for AND Logic equation (A, B, C and D).
6.
Opto I/P
Rem.Rst*
654321
000000
6ïƒ S6……..1ïƒ S1
1 = assigned ; 0 = not assigned
This cell sets the Opto I/P 1 – Opto I/P 6 for desired function.
*Note: The functions which can be assigned to Output Relay, LED Green, LED RED, AND Logic
and Opto I/P are listed in Chapter 8: Monitoring and Control.
2.9 O/P RELAY CONFIG Settings
2. Contact HR/SR 000000 1= HR / 0 = SR
This setting specifies the reset mechanism (manual/hand reset or self reset) for O/P relay contacts.
3. O/P-1 Open Time 0.05 S 0s to 1s step of 0.01s
4. O/P-2 Open Time 0.05 S 0s to 1s step of 0.01s
7. O/P-5 Open Time 0.05 S 0s to 1s step of 0.01s
8. O/P-6 Open Time 0.05 S 0s to 1s tep of 0.01s
This setting specifies the time duration for which the output contacts holds its state after non availability of the command to the O/P
contact.
9. LED G HR/SR 0000 1= HR / 0 = SR
This setting specifies the reset mechanism (manual/hand reset or self reset) for Green LED.
10. LED R HR/SR 0000 1= HR / 0 = SR
