P50 Agile P253
7 Protection Parameter Settings
P253/EN M/C
7-17
Sr. No
Parameter
Default setting
Setting Range
This setting determines the type of reset/release characteristics. IDMT applicable for IEEE curves only.
7.
IN2>1 RTMS
1
0.025 to 1.2 step 0.005
This setting determines the reset/release time for IEEE IDMT characteristic
8. IN2>1 tRESET 0.01 S 0 to 100s step 0.01s
This setting determines the reset/release time for Definite Time (DT) and all IDMT curve
9. IN2>1 2H Blocking Disabled Enabled/Disabled
This setting determines the enabling/disabling of blocking first stage derived earth fault element due to presence of inrush current.
If IN2>1 Blocking and 2nd Harmonic both settings are enabled, then (IN2
>1) trip command will be blocked in case 2nd harmonics content
in any phase is above the 2ndHarm Thresh. and fundamental current is below I> lift 2H setting. (Set in SYSTEM CONFIG Menu.)
2.12.4.2 IN2>2 Function
Sr. No Parameter Default setting Setting Range
1. IN2>2 Function IEC S Inverse
Disabled/DT/IEC S Inverse/S
Inverse 1.3Sec /
IEC V Inverse/IEC E Inverse/UK LT Inverse/
IEEE M Inverse/IEEE V Inverse/IEEE E
Inverse/US Inverse/US ST Inverse
This setting determines the tripping characteristic for the second stage derived earth fault element.
2. IN2>2 Current Set 1*In
If DT 0.10 to 35*In step 0.01*In
If IDMT then 0.10 to 4*In step 0.01*In
This setting determines the pick-up setting for second stage derived earth fault element.
3. IN2>2 Time Delay 1 S 0 to 200s step 0.01s
This setting determines the time-delay for the definite time setting if selected for second stage of derived earth fault element.
4.
IN2>2 TMS
1
0.025 to 1.200 step 0.005
This time multiplier setting is used to adjust the operating time of the IEC / UK IDMT characteristic.
5. IN2>2 Time Dial 1 0.01 to 100 step 0.01
This time multiplier setting is used to adjust the operating time of the IEEE / US IDMT curves.
6. IN2>2 Reset Char DT DT/IDMT
This setting determines the type of reset/release characteristics. IDMT applicable for IEEE curves only.
7.
IN2>2 RTMS
1
0.025 to 1.2 step 0.005
This setting determines the reset/release time for IEEE IDMT characteristic
8. IN2>2 tRESET 0.01 S 0 to 100s step 0.01s
This setting determines the reset/release time for Definite Time (DT) and all IDMT curve
9. IN2>2 2H Blocking Disabled Enabled/Disabled
This setting determines the enabling/disabling of blocking second stage derived earth fault element due to presence of inrush current.
If IN2>2 Blocking and 2nd Harmonic both settings are enabled, then (IN2
>2) trip command will be blocked in case 2nd harmonics content
in any phase is above the 2ndHarm Thresh. and fundamental current is below I> lift 2H setting. (Set in SYSTEM CONFIG Menu.)
2.12.4.3 IN2>3 Function
Sr. No
Parameter
Default setting
Setting Range
1. IN2>3 Function IEC S Inverse
Disabled/DT/IEC S Inverse/S
Inverse 1.3Sec /
IEC V Inverse/IEC E Inverse/UK LT Inverse/
IEEE M Inverse/IEEE V Inverse/IEEE E
Inverse/US Inverse/US ST Inverse
This setting determines the tripping characteristic for the third stage derived earth fault element.
2. IN2>3 Current Set 1*In
If DT 1.0 to 35*In step 0.01*In
If IDMT then 0.10 to 4*In step 0.01*In
This setting determines the pick-up setting for third stage derived earth fault element.
