GE P50 Agile P253 User Manual

P50 Agile P253
7 Protection Parameter Settings
P253/EN M/C
7-21
Sr. No
Parameter
Default setting
Setting Range
This setting determines the enabling/disabling of blocking third stage Negative sequence overcurrent element due to presence of inrush
current.
If I2>3 Blocking and 2nd Harmonic both settings are enabled, then (I2>3) trip command will be blocked in case 2nd harmonics content in
any phase is above the 2ndHarm Thresh. and fundamental current is below I> lift 2H setting. (Set in SYSTEM CONFIG Menu.)
2.12.8 CB FAIL Settings
Sr. No
Parameter
Defaults setting
Setting/Ranges
1.
CB Fail Status
Enabled
Disabled/Enabled
This setting is used to enable (activate) or disable (turn off) the CB Fail Status
2. CB Fail Timer 0.1 S 0 to 50s step 0.01s
This setting sets the time delay in which the CB opening must be detected.
3. CBF Reset CB Open + I<
1=I< Only
2=CB Open + I<
3=Prot Reset + I<
4= CB Open
This setting determines the elements that will reset the CB fail timer for CB Failures
4.
I<
1*In
0.05 - 3.2*In step 0.01*In
This setting determines the current threshold, which will reset the CB Fail timer for Overcurrent based protection
5. IN< 1*In 0.05 - 3.2*In step 0.01*In
This setting determines the current threshold, which will reset the CB Fail timer for Earth fault based protection
6. Remove I> Start Disabled Disabled/Enabled
This setting for removing phase over current start signal following CBF operation
7.
Remove IN> Start
Disabled
Disabled/Enabled
This setting for removing earth over current start signal following CBF operation
2.12.9 STALL DETECTION
Sr. No Parameter Defaults setting Setting/Ranges
1. Start Criteria I 52a / I / (52a+I)
This setting determines the start detection criteria
2. Prolonged Start Enabled Disabled/Enabled
This setting enables/disables the prolonged start function
3.
Starting Current
5*In
1 - 5*In step 0.1*In
This setting determines the starting current threshold.
4. Prol. Start Time 15 S 1s to 200s step 0.01s
This setting determines the starting time delay.
5. Stall Rotor Strt Enabled Disabled/Enabled
This setting enables/disables the stalled rotor detection during starting.
6.
Stall Detection
Enabled
Disabled/Enabled
This setting enables/disables the stalled rotor detection function during normal running.
7. Stall Setting 2.5*In 1 to 5*In step 0.1*In
This setting determines the stalled rotor detection current threshold.
8. Stall Time 6 S
1s to 199s step 0.01s
This setting determines the stalled rotor time delay associated with stall rotor current threshold.
