7 Protection Parameter Settings
This setting enables/disables hot start status function
2. Hot Start NB 2 1 to 5 step of 1
This setting determines the number of hot starts allowed.
3. Cold Strt Stat Disabled Disabled/Enabled
This setting enables/disables cold start status function
This setting determines the starting time delay.
5. Supervising Time 10 Mins 1 to 120 min step 1 min
This setting enables/disables the supervision period for the number of hot and cold starts.
6. T.Betw.St Status Disabled Disabled / Enabled
This enables/ disables the setting for time between two starts.
This setting determines the minimum time between two starts.
8. Inhib. Strt Time 10 Mins 1 to 120min step 1min
This setting determines the length of start inhibit signal once the maximum limit of either of the two counters (cold and hot) has been
reached
2.12.11 VIEW RECORDS
Sr. No Parameter Display value on LCD
1. Fault Record Display the Records of fault i.e. parameter value, flag of fault & date and time of Fault
2. Event Record Display of all digital events with time stamping (max 512 events)
3. Maint Record Display of error generated by relay if any, in case of failure of hardware
Display of alarm generated by relay & date and time of generated alarm.
