GE P50 Agile P253 User Manual

8 Monitoring & Control
P50 Agile P253
8-10
P253/EN M/C
Function
Description
StrtDFail Start detection fail indication
CloseFail
CB Close Fail Alarm (during control operation)
Open Fail
CB Open Fail Alarm (during control operation)
Relay OK Relay healthy
EmerRest Emergency start
Strt Stal Stall during motor starting
Suprvsn T Supervision time during motor start
Inhb Strt
Motor start inhibit
Tbet Strt
Time between Starts
Gen Trip General Trip
Trip L1 Trip in phase A
Trip L2 Trip in phase B
Trip L3 Trip in phase C
Trip I>1
Trip in O/C stage 1
Trip I>2
Trip in O/C stage 2
Trip I>3 Trip in O/C stage 3
Trip I2>1 Trip in Neg seq. O/C stage 1
Trip I2>2 Trip in Neg seq. O/C stage 3
Trip I2>3 Trip in Neg seq. O/C stage 2
TripIN1>1
Trip in Measured EF stage 1
TripIN1>2
Trip in Measured EF stage 2
TripIN1>3 Trip in Measured EF stage 3
TripIN2>1 Trip in Derived EF stage 1
TripIN2>2 Trip in Derived EF stage 2
TripIN2>3
Trip in Derived EF stage 3
THOL Trip
Trip in Thermal overload
THOL Lkt
Thermal lockout
Trip I< Trip in Under Current
CBF Trip Trip in Breaker Fail
Trip Prln
Prolong trip
Trip Stal
Motor stall
Rotor Lck
Locked Rotor
Motor Strt Motor start signal before successful start
Motor Run Motor run signal after successful start
CBOpr Alm CB operation Alarm
OptoI/P 1 Opto Input 1
OptoI/P 2
Opto Input 2
OptoI/P 3
Opto Input 3
OptoI/P 4 Opto Input 4
OptoI/P 5 Opto Input 5
OptoI/P 6 Opto Input 6
AndLogicA AND logic equation A
AndLogicB
AND logic equation B
AndLogicC
AND logic equation C
