P50 Agile P253
9 SCADA Communications
P253/EN M/C
9-5
Sr. No.
Function
Code
Register
No. of
Regs.
Format
Reg.
Type
Address Map
1
Product
Information
03
Manufacturer Name
10
20-Bytes
ASCII
R 40001 40010
Relay Name 10
20-Bytes
ASCII
R 40011 40020
Model 10
20-Bytes
ASCII
R 40021 40030
Version 10
20-Bytes
ASCII
R 40031 40040
Relay Description 10
20-Bytes
ASCII
R 40041 40050
Sr. No.
Function
Code
Register
No. of
Regs.
Format
Reg.
Type
Address
Map
2
Relay
Configuration
03
Num Status (s)
1
16-bit
R
40258
Num Controls (c) 1 16-bit R 40259
Num Parameters (p) 1 16-bit R 40260
Num Faults (f) 1 16-bit R 40261
Sr. No.
Function
Code
Register
No. of
Regs.
Format
Reg.
Type
Address Map
3
Time Synchronization
(Unicast/Broadcast)
03/16
Year 1 16-bit R/W 42049
Month- Day 1 16-bit R/W 42050
Hour, Min 1 16-bit R/W 42051
Milliseconds
1
16-bit
R/W
42052
