GE P50 Agile P253 User Manual

9 SCADA Communications
P50 Agile P253
9-6
P253/EN M/C
For General Electric P50 Agile relays on Modbus, time synchronization is possible via a broadcast
command to 800H (4x02049 through 4x02052). The format is inverted IEC 870-5-4 CP56Time2a
Words
7
6
5
4
3
2
1
0
7
6
5
4
3
2
1
0
1 0 0 0 0 0 0 0 0 Year 00..99
2
0 0 0 0
Month
Day of Week
Day of Month 1..12 1..7 1..31
3 SU 0 0 Hours Iv 0 Minutes 0..23 0..59
4 Milliseconds Hi Milliseconds Lo 0..59999 (seconds + milliseconds)
Su (=0 Standard, =1 Summer Time)
iv
(=0 valid, =1 non-valid or non-synchronised in system case)
First Day of week is Monday
Sr. No.
Function
Code
Register
No. of
Regs.
Format
Reg.
Type
Address
Map
4
Status and Logical
Status
02
Gen Strt 1 1-bit R 12769
Strt L1 1 1-bit R 12770
Strt L2 1 1-bit R 12771
Strt L3 1 1-bit R 12772
Strt I>1
1
1-bit
R
12773
Strt I>2
1
1-bit
R
12774
Strt I>3 1 1-bit R 12775
Strt I2>1 1 1-bit R 12776
Strt I2>2 1 1-bit R 12777
Strt I2>3 1 1-bit R 12778
Strt IN1>1
1
1-bit
R
12779
Strt IN1>2
1
1-bit
R
12780
Strt IN1>3 1 1-bit R 12781
Strt IN2>1 1 1-bit R 12782
Strt IN2>2 1 1-bit R 12783
Strt IN2>3 1 1-bit R 12784
THOL Alm
1
1-bit
R
12786
Strt I<
1
1-bit
R
12788
Strt CBF 1 1-bit R 12789
I> BCBF 1 1-bit R 12790
IN1> BCBF 1 1-bit R 12791
Test Mode 1 1-bit R 12792
CloseFail
1
1-bit
R
12793
Open Fail 1 1-bit R 12794
Relay OK 1 1-bit R 12795
