2 HARDWARE DESIGN
The P253 hardware comprises of the following main components:
• Housing, consisting of a front panel and connections at the rear
• Microcontroller module
• Analogue input module
• Digital input module
• Digital output module
• Communication module
• Power supply unit
• Human machine interface (HMI) module
Figure 1: P253 general assembly
