GE P50 Agile P253 - 5. Mechanical tests

13 Technical Specifications
P50 Agile P253
13-10
P253/EN M/C
4.9
Damped oscillatory
magnetic field
EN61000-4-10:1993 +
A1:2001, Level 5
Class 5: 100A/m field applied in all planes at 100kHz / 1MHz with burst duration of 2
Sec.
4.10
Damped oscillatory
test
EN 61000-4-18: 2007 +
A1:2010
1) 100kHz and 1MHz slow damped oscillatory applied in common mode at 2.5 KV
2) 3MHz, 10MHz, 30MHz fast damped oscillatory applied in common mode at 1 KV
5.
Mechanical tests
5.1
Vibration response
test
EN 60255-21-1:1996
Class 2
Frequency range
10 Hz to 150 Hz
Crossover frequency 58 to 60 Hz
Peak displacement before crossover
0.075mm
Peak acceleration after crossover 1 gn
No. of sweep cycles per axis
1
EUT condition Energised
5.2
Vibration endurance
test
EN 60255-21-1:1996
Class 2
Frequency range 10 to 250Hz
Peak acceleration 2 gn
No. of sweep cycles per axis 20
EUT condition Non energised
5.3 Shock response test
EN 60255-21-2:1996
Class 2
Peak acceleration 10 gn
Pulse duration 11 ms
No. of pulses in each direction 5
EUT condition Energised
5.4 Shock endurance test
EN 60255-21-2:1996
Class 2
Peak acceleration 30 gn
Pulse duration 11 ms
No. of pulses in each direction 3
EUT condition Non energised
5.5 Bump test
EN 60255-21-2:1996
Class 2
Peak acceleration 20 gn
Pulse duration 16 ms
No. of pulses in each direction 1000
EUT condition Non energized
5.6 Seismic test
EN 60255-21-3:1995
(Class 2 - 2g peak)
Frequency range
1 to 35 Hz
Crossover frequency
8 Hz
Peak displacement before crossover X 7.5 mm
Peak displacement before crossover Y 3.5 mm
Peak acceleration after crossover X 2 gn
