Note: Press the CLEAR Key to DISCARD settings.
SET For Save
CLEAR For Cancel
Step 10: When the CLEAR key is pressed, it will discard the changes
and the relay will move to the next option.
2.2 Password Entry
To modifiy the settings you will need password access. You will be asked for a password before
you can make any of the following changes. The default password is 0000.
1. When you press the EDIT key a flashing cursor appears at the right most character field
of the password by default. Press the up or down cursor keys to change each character.
2. Use the left and right cursor keys to move between the character fields of the password.
3. Press the SET key to confirm the password. After entering a valid password the
Password OK message appears indicating that the password is correct. The user can
now start editing the settings. If the correct password has not been entered, the password
prompt page appears again. To stop this prompt press the CLEAR key.
4. A new password can be set using the Password cell in the SYSTEM DATA menu.
5. If the keypad is inactive for 15 minutes the user will again be prompted for a password
entry.
