P50 Agile P253
5 Configuration
P253/EN M/C
5-9
2.3 Menus
2.3.1 Default Display
After Power ON or when the PROT.RESET + EDIT keys are pressed the relay will display the
following message.
P50 Agile P253
Motor Protect’n
This window will flash momentarily showing the following.
Relay Name: P50 Agile P253,
Relay Type : Motor Protection
Then the control will automatically move to next option.
ID = 1
SW = V1.04
This window will flash momentarily showing the following :-
Unit ID = 1
Software Version =V1.04
Then the control will automatically move to the default window.
SYSTEM DATA
2.3.2 Main Menu Contents
SYSTEM DATA
Password protected window for “SYSTEM DATA’’ setting i.e. Language,
Description, Model Number, Serial Number, Software Version,
Frequency, USB Address, USB Parity, USB Baud Rate, Password,
Active Group, Opto I/P Status, Relay O/P Status. CB Open/Close, Opto
I/P and Config Port.
VIEW RECORDS
Menu to view Fault Record, Event Record, Maint Record and Alarm
records.
MEASUREMENTS
This menu displays the measurements values of various parameters
under submenu Measurement 1 and 2
Measurement 1 (i.e. Phase current, measured and derived earth
current, negative, positive phase sequence current and zero sequence
current) as per phase/earth CT ratio, rms value of phase current, BOC
(Breaker Operation Counter), TC (Trip Counter), BOT (Breaker
Operating Time), and
Measurement 2 (i.e. Thermal State, Load Current, Time to Th Trip, Nb
of Th Trip, Last Start Time, Last St Current, Nb Hot St Allow, Nb Cold St
Allow, Time to Next St, Total Nb of Strt, Nb Emergency Rst and Motor
Run Time)
CB CONTROL
Password protected window for “CB CONTROL” settings
i.e. TCS
Alarm, TCS Timer, CB Open S’vision (Enabled / Disabled), CB Open
Time, CB Open Alarm (Enabled / Disabled), CB Open Oper, CB Control
By, Close Pulse Time, Open Pulse Time and Emergency Rest. (Yes/No).
