Alarm Record

This window will show Alarm Record

TCS Alarm

This window shows latest alarm.

24/09/2014

12:35:40:025

This window shows the date and time of alarm.

2.3.5 Measurement Menu

2.3.5.1 View Contents- Measurement 1 Submenu

MEASUREMENTS

Menu to view the Measurement 1 & Measurement 2

Measurement 1

Submenu to view following measurements :

Phase current, Measured and derived earth c

urrent, Negative and

Positive phase sequence current and zero sequence current) as per CT

Primary and Secondary current selection, RMS value of Phase Current,

BOC (Breaker Operation Counter), TC (Trip Counter), BOT (Breaker

Operating Time),

IA = 0 A

IB = 0 A

This window shows primary value of current in phase A and B taking in

to account phase CT ratio.

IC = 0 A

IN1 = 0 A

This window shows primary value of current in phase C and measured

earth current taking in account phase CT and earth CT ratio respectively.

IN2 = 0 A

I0 = 0 A

This window shows primary value of internally derived earth current and

zero sequence current.

I1 = 0 A

I2 = 0 A

This window shows primary value of positive sequence current and

negative sequence current.

GE P50 Agile P253 User Manual
