GE P50 Agile P253 User Manual

5 Configuration
P50 Agile P253
5-18
P253/EN M/C
ia = 0.00 A
ib = 0.00 A
This window shows secondary value of current in phase A and phase B.
ic = 0.00 A
in1 = 0.00 A
This window shows secondary value of current in phase C and
measured earth current.
in2 = 0.00 A
i0 = 0.00 A
This window shows secondary value of internally derived earth current
and zero sequence current.
i1 = 0.00 A
i2 = 0.00 A
This window shows secondary value of positive sequence current and
negative sequence current.
Irms A = 0.00 A
Irms B = 0.00 A
This window shows secondary value of RMS current in phase A and
Phase B.
Irms C = 0.00 A
BOC : 0
This window shows secondary value of RMS current in phase C and
Breaker operation counter.
TC : 0
BOT : 0 msec
This window shows Trip Counter and Breaker Operating Time
2.3.5.2 View Contents- Measurement 2 Submenu
MEASUREMENTS
This menu is to view the Measurement 1 & Measurement 2
Measurement 1
Submenu to view measurements related to phase current, earth current,
breaker operation, trip counter and breaker operating time.
