EARTH FAULT 2
Password protected window for
i.e. IN2>1 Function,
IN2>2 Function and IN2>3 Function which can be set as Disabled / DT /
IEC S Inverse/ S Inverse (1.3Sec)/ IEC V Inverse/ IEC E Inverse/ UK LT
Inverse /IEEE M Inverse/ IEEE V Inverse/ IEEE E Inverse /US Inverse
/US ST Inverse.
IN2>1 Function
IEEE M Inverse
Editable setting
By using the (+ /5) or (- /6) key, IN2>1 Function is set as
IEEE M Inverse.
IN2>1 Current Set
1.00 A
Editable setting
By using the (+ /5) or (- /6) key, the desired IN2>1 Current Setting
can be set. The setting range is from 0.1 to 4 In in steps of 0.01 In.
By using the (+ /5) or (- /6) key, the desired IN2>1 Time Dial can be
set. The setting range is from 0 to 200 in steps of 0.01.
By using the (+ /5) or (- /6) key, the desired IN2>1 Reset Char
Function can be set as IDMT / DT (Definite Time).
IN2>1 tRESET
0.01 S
Editable setting
By using the (+ /5) (- /6) key, the desired IN2>1 tRESET can be set.
The setting range is from 0 to 100s in steps of 0.01s.
Note: This setting is applicable if IN2>1 Reset Char set as DT
IN2>1 RTMS
1.000
Editable setting
By using the (+ /5) or (- /6) key, the desired IN2>1 RTMS can be set.
The setting range is from 0.025 to 1.2 in steps of 0.005
Note: This setting is applicable if IN2>1 Reset Char set as IDMT
IN2>1 2HBlocking
Disabled
By using the (+ /5) or (- /6) key, IN2>1 2HBlocking function can be
Enabled / Disabled.
2.3.16.6.4
Edit Settings
(if IN2>1 Function is selected for DT)
GROUP 1
Password protected window for “GROUP 1’’ settings:
SYSTEM CONFIG, OVERCURRENT, NEG SEQUENCE O/C, EARTH
FAULT 1, EARTH FAULT 2, THERMAL OVERLOAD, LOSS OF LOAD,
CB FAIL, STALL DETECTION and LIMITS NB STARTS.
Password protected window for Earth Fault 2 i.e. IN2>1 Function,
IN2>2 Function and IN2>3 Function which can be set as Disabled / DT /
IEC S Inverse/ S Inverse (1.3Sec)/ IEC V Inverse/ IEC E Inverse/ UK LT
Inverse /IEEE M Inverse/ IEEE V Inverse/ IEEE E Inverse /US Inverse
