5 Configuration
P50 Agile P253
5-50
P253/EN M/C
IN2>1 Function
DT
Editable setting
By using the (+ /5) or (- /6) key, IN2>1Function is set as DT.
IN2>1 Current Set
1.00 A
Editable setting
By using the (+ /5) or (- /6) key, the desired IN2>1 Current Setting
can be set. The setting range is from 0.1 to 35 In in steps of 0.01 In.
Note: For I>3 Function, the setting range is from 1 to 35 In in steps of
0.01 In
IN2>1 Time Delay
1.00 S
Editable setting
By using (+ /5) or (- /6) key, the desired IN2>1 Time Delay can be
set. The setting range is from 0 to 200s in steps of 0.01s.
IN2>1 Reset Char
DT
Read-only
The IN2>1 Reset Char Function is fixed i.e. DT (Definite Time).
IN2>1 tRESET
0.01 S
Editable setting
By using the (+ /5) or (- /6) key, the desired IN2>1 tRESET can be
set. The setting range is from 0 to 100s in steps of 0.01s.
IN2>1 2H Blocking
Disabled
Editable setting
By using the (+ /5) or (- /6) key, IN2>1 2H Blocking function can be
Enabled / Disabled.
Note: The settings of IN2>2 Function and IN2>3 Function to be set in similar manner as that of IN2>1
Function.
2.3.16.7 Group 1 –Thermal Overload Submenu
2.3.16.7.1
Edit Settings
(if settings are disabled)
GROUP 1
Password protected window for
“GROUP 1’’
setting :
SYSTEM CONFIG, OVERCURRENT, NEG SEQUENCE O/C, EARTH
FAULT 1, EARTH FAULT 2, THERMAL OVERLOAD, LOSS OF LOAD,
CB FAIL, STALL DETECTION and LIMITS NB STARTS.
THERMAL OVERLOAD
Password protected window for Thermal Overload i.e. Inh. Trip Dur St,
K Coefficient, Thermal Trip, Thermal Alarm, Thermal Const. T1, Thermal
Const. T2, Cooling Const. Tr, Thermal Lockout and K.
