P50 Agile P253
5 Configuration
P253/EN M/C
5-53
Cooling Const.Tr
60 Mins
Editable setting
By using the (+ /5) or (- /6) key, the desired Thermal Const.Tr can
be set. The setting range is from 1 to 999 Mins in steps of 1 Min.
Thermal Lockout
Enabled
Editable setting
By using the (+ /5) or (- /6) key, Thermal Lockout is Enabled.
Lockout Thresh.
90 %
Editable setting
By using the (+ /5) or (- /6) key, the desired Lockout Thresh. can be
set. The setting range is from 25 to 100% in step of 1%
K
1
Editable setting
By using the (+ /5) or (- /6) key, the desired K value can be set. The
setting range is from 1 to 1.5 in steps of 0.01.
2.3.16.8 Group 1 – Loss of Load Submenu
2.3.16.8.1
Edit Settings
(if I<1 Status is disabled)
GROUP 1
Password protected window for
“GROUP 1’’
settings:
SYSTEM CONFIG, OVERCURRENT, NEG SEQUENCE O/C, EARTH
FAULT 1, EARTH FAULT 2, THERMAL OVERLOAD, LOSS OF LOAD,
CB FAIL, STALL DETECTION and LIMITS NB STARTS
LOSS OF LOAD
Password protected window for Loss of Load
i.e. I<1 Status
(Enabled/Disabled), I<1 Current Set, I<1 Time Delay, T inhib.
I<1 Status
Disabled
Editable setting
By using the (+ /5) or (- /6) key, I<1 Status can be set as Disabled.
2.3.16.8.2
Edit Settings
(if I<1 Status is enabled)
GROUP 1
Password protected window for “GROUP 1’’ settings:
SYSTEM CONFIG, OVERCURRENT, NEG SEQUENCE O/C, EARTH
FAULT 1, EARTH FAULT 2, THERMAL OVERLOAD, LOSS OF LOAD,
CB FAIL, STALL DETECTION and LIMITS NB STARTS.
LOSS OF LOAD
Password protected window for Loss of Load i.e. I<1 Status
Enabled/Disabled, I<1 Current Set, I<1 Time Delay, T inhib.
