5 Configuration
P50 Agile P253
5-54
P253/EN M/C
I<1 Status
Enabled
Editable setting
By using the (+ /5) or (- /6) key, I<1 Status is set as Enabled.
I<1 Current Set
1.00 A
Editable setting
By using the (+ /5) or (- /6) key, the desired I<1 Current Setting can
be set. The setting range is from 0.1 to 1 In in steps of 0.01 In
I<1 Time Delay
1.00 S
Editable setting
By using the (+ /5) or (- /6) key, the desired I<1 Time Delay can be
set. The setting range is from 0.2s to 100s in steps of 0.01s.
T inhib
12.00 S
Editable Setting
By using the (+ /5) or (- /6) key, the desired T inhib can be set. The
setting range is 0.05s to 300s in steps of 0.1s
2.3.16.9 Group 1 –CB Fail Submenu
2.3.16.9.1
Edit Settings
(if CB Fail Status is disabled)
GROUP 1
Password protected window for “GROUP 1’’ settings:
SYSTEM CONFIG, OVERCURRENT, NEG SEQUENCE O/C, EARTH
FAULT 1, EARTH FAULT 2, THERMAL OVERLOAD, LOSS OF LOAD,
CB FAIL, STALL DETECTION and LIMITS NB STARTS.
CB FAIL
Password protected window for CB FAIL settings i.e. CB Fail Status, CB
Fail Timer, CB Reset, I<, IN<, Remove I> Start and Remove IN> Start.
CB Fail Status
Disabled
Editable setting
By using the (+ /5) or (- /6) key, CB Fail Status is set as Disabled.
I<
1.00 A
By using the (+ /5) or (- /6) key, the desired I< can be set. The setting
range is from 0.05 to 32 In in steps of 0.01 In
IN<
1.00 A
By using the (+ /
5
) or (- /
6
) key, the desired IN< can be set. The
setting range is from 0.05 to 32 In in steps of 0.01 In
