Batteries
14 PACSystems* Controllers Battery and Energy Pack Manual GFK-2741D
RX3i Battery Installation Diagram
RX7i Battery Installation Diagram
1.
Notch at base of battery
compartment
Connectors
2.
An earlier version RX7i CPU may not have a
slot in its battery door. For these CPUs, replace
the door (supplied with the IC698ACC701
replacement battery).
Connectors
Battery Compartment
Notch in Battery Cover
Battery
Compartment
