Energy Packs
GFK-2741D June 2015 17
3. Energy Packs
An Energy Pack is used in conjunction with a Controller to preserve user memory in the Controller during power
fluctuations or outages.
If system power is lost, the Energy Pack maintains power long enough for a Controller to write its user memory
contents to non-volatile memory. When system power is restored, the user memory is restored if the Controller is
configured to power up from RAM.
3.1 Energy Pack Compatibility
The correct Energy Pack must be used with the corresponding controller. Do not attempt combinations except
those shown as “compatible” in the table below:
Energy Pack
Cap Pack
Controller
ICRXIACCEPK01A
ICRXIACCCPK01A
3.2 PACSystems RXi Energy Pack (ICRXIACCEPK01A)
3.2.1 Specifications
Part Numbers
Energy Pack. Includes base, Cap Pack module and Energy Pack to Controller cable
Replacement Cap Pack module
Replacement 0.3m (12”) Energy Pack to Controller cable
Functional Specifications
114.05 × 77.47 × 63.75 mm
(4.49” × 3.05” × 2.51”)
36 W + connected device power requirement
Capacitor Pack life expectancy
Environmental Specifications
The Energy Pack shall be installed in a location that is not exposed to corrosive gases or liquids, rain, or direct
sunlight, and that meets the environmental specifications listed below.
Operating Temperature, surrounding air
-40C to +85C (-40°F to 185°F)
5% to 95%, non-condensing
Restricted Access Area and Pollution Degree 2 environment as defined below.
