Place the door back on the dryer front panel,
making sure the latch is engaged and the hinge
is sitting in the two openings in the dryer front.
Assemble the door to the front cabinet, using
2 screws (#10 x 0.75″ tapping screws).
Install 2 x B
screws

Install the new left-hand hinge cap (from the
reversibility kit) onto the hinge, by opening the
dryer door and screwing the hinge cap into place.
#$)(0E4C74A4<08=8=620?B0=32>E4AB8=20B4
H>DF0=CC>A4E4AB4C7478=640608=
1 x C Screw
in hinge cap
Hinge cap
