16
Remove the control board assembly:
1. Remove the control panel. (See 1. Control Panel.)
Note: In the following step, the knob is held in place by 4 plastic clips and may require
some effort to remove.
2. Remove the knob by pulling it straight out.
3. Remove the 4 (6-mm) hex-head screws that hold the control board assembly to
the control panel.
4. Remove the control board assembly
from the control panel.
5. Remove the cycle selection buttons.
CONFIDENTIAL AND PROPRIETARY INFORMATION-NOT FOR PUBLIC DISCLOSURE. September 2008
