24
Dispenser Assembly (cont.)
Operation of the dispenser can be checked by using service test mode t15. (See
Service Test Mode.)
Specific failures associated with the dispenser can initiate error code E9. (See
Service Test Mode.)
Caution: When testing the diverter motor, DO NOT remove the wiring harness from
the diverter motor unless replacing the motor assembly. The motor assembly
has a special locking connector and the wiring harness will not stay reconnected
if removed and reinstalled on the same motor.
To remove the dispenser assembly:
1. Remove the top and control panels. (See 1. Top and Control Panels.)
2. Remove the gasket inlet hose from the clip attached to the dispenser.
CONFIDENTIAL AND PROPRIETARY INFORMATION-NOT FOR PUBLIC DISCLOSURE. September 2008
