Inverter (cont.)
5. Unplug washer, then check motor
resistance.
(See Motor Assembly.)
6. If 120 VAC is present at the AC
input harness and motor
resistance is correct, replace the
inverter.
Note: If the inverter overheats, the
washer will stop for 5 minutes.
Note
• The motor wire harness is soldered to the
inverter. Any fault in the inverter or motor
wire harness requires inverter
replacement.
• The motor ground wire connector utilizes a
releasing locking tab.
ELECTRICAL TERMINAL
RELEASE/LOCKING TAB
