44
Door (cont.)
Note: Place the door on a soft, protected
flat surface so that the door glass
faces up. (The door should rest on the
handle side.)
4. Remove the 10 Phillips-head screws
that hold the door cover and door
strike to the door frame.
5. Lift and unsnap the door cover from the door
frame.
6. Lift the door glass out of the door frame.
7. Remove the 9 Phillips-head screws
that attach the protect cover and ring to
the door frame.
CONFIDENTIAL AND PROPRIETARY INFORMATION-NOT FOR PUBLIC DISCLOSURE. September 2008
