52
Service Test Mode (cont.)
Verifi es that each key operates correctly.t07 Key Continuity
Verifies all LEDs operate correctly.t06 UI Test
Checks the memory on the user interface control
board, then the memory on the Power Board.
t05 EEPROM Test
Tests the washer vibration by spinning to the extra
high spin speed as fast as possible. Note: No out
of balance detection will be performed here, so the
washer will spin up regardless of the out of balance
that is placed in the drum.
t04 Vibration Test
Checks the software version.t03 Version Information
Checks for any error codes reported by the controls.t02 Error Codes
Allows changing the configuration of the control for
different models.
t01 Configure UI (User
Interface)
DescriptionTest Mode
CONFIDENTIAL AND PROPRIETARY INFORMATION-NOT FOR PUBLIC DISCLOSURE. September 2008
