56
Diagnostic Tests (cont.)
Fills to normal level. Displays “Foam Level” until fi ll is complete, then
shows “Normal Wash Level”
Start
Fills to foam level. Displays “Tub Empty” until fi ll is complete;
then shows “Foam Level”
Start
Unit begins to drain. When draining is complete, displays “Tub Empty”
Enter
Water
Level
Sensor
t09
Interrupts draining and returns to service mode
Power
Begins running the drain pump
Enter
Pump Test
t08
Returns to service mode screenPower
Beep sounds as button is pressed
Any Button
but Power
Begins testingEnter
Key
Continuity
t07
Returns to service mode screen
Power
Lights up LEDs on the left side of UI and VFD; then lights up
the right side LEDs
EnterUI Test
t06
Sequence
Service Mode
Test
CONFIDENTIAL AND PROPRIETARY INFORMATION-NOT FOR PUBLIC DISCLOSURE. September 2008
To Next Page
