Measurement, Protection and Control
24
SecoVac 3.3kV-27kV Embedded Pole Vacuum Circuit Breaker
Features
Overview
Protection and control
ő
Up to 32 Programmable digital inputs
ő
Up to 16 digital outputs
ő
Trip Circuit Supervision
ő
Redundant power supply option
ő
ő
ő
Alarms panel
as a comprehensive protection, control,
metering and monitoring package. The
microprocessor based architecture
applications that complies with the most
relevant international standards.
All the elements required for each
application have been integrated into a
and simple utilization. The low number of
components, thanks to the use of state-
of-the-art but mature technology, deliver
a very high reliability.
Hardware inputs and outputs have been
designed in a modular way that allow
easy migration from simple to more
complex applications.
The control functions include a full-
scheme virtual PLC with an optional
graphical display. The combination of
both elements provide total control for
a bay. This means real-time monitoring
of breakers and selector switches, open
and close commands supervised by the
programmable interlockings and metering
User interface
ő
Large graphic (16 x 40) or regular (4 x 20) character display
ő
Easy-to-use control via Shuttle key
ő
Front USB port or standard RS232
ő
Rear wire 10/100BaseTX Ethernet for LAN connection
ő
ő
ő
ő
ő
EnerVista
TM
Integrator providing easy integration of data in the
Monitoring and metering
ő
Energy metering
ő
Demand metering
ő
Trip circuit monitoring
ő
Oscillography
screens.
208V for voltage in metering range.
Monitoring functions include a 479
event recorder, and a programmable
oscillography recorder.
capability and option make the product
very unique. These units include
a maximum of three independent
communication ports: COM1, COM2
and COM3, with many physical choices
through the use of two removable plug-
and-play boards.
a powerful built-in virtual PLC. This PLC
can be programmed according to the IEC
61131-3 language by functional block
diagrams.
and with 8 to 16 outputs depending on
with a separate debounce time to tailor
customer requirements.
ő
Data logger
ő
Sequence of event
ő
Self diagnostic
Metering
metering values.
ő
Current: Ia, Ib, Ic, In, Ig, Isg
ő
Phase-to-phase and phase-to-ground
voltage values for bus and line: Van,
Vbn, Vcn, Vab, Vbc, Vca, Vx
ő
Active power (per phase and total) : Wa,
Wb, Wc, W
ő
Reactive power (per phase and total) :
VARa, VARb, VARc, VAR
ő
Power factor (per phase and total)
ő
Frequency
ő
These signals are available for local
display and accessible remotely using
communications
Recording functions
The recording functions within the Multilin
ő
Event recorder capable of storing 479
time-tagged events (1 true millisecond
accurate tagging)
ő
Up to 20 separate oscillography records
can be stored in memory. The capacity
of each record will depend on the type of
oscillo selected (1 Mbyte/Max. No. Osc)
