Measurement, Protection and Control
SecoVac 3.3kV-27kV Embedded Pole Vacuum Circuit Breaker
EN F650 BLOCK F.CDR
22
F650 Digital Bay Controller
R
R
METERING
52
3
3
1
1
1
79
51G 67G
67SG
67P
50SG
51SG
50IG
50N
51N
67N
59X
27X
59NH
25
3V_0
51PL/V
51PH/V
Monitoring
CLOSE
TRIP
50G
1
50BF
1
49
3
50PH
3
50PL
3
46
3
48
3
32FP
3
32
3
32N
3
3
BROKEN
CONDUCTOR
3
3
3
3
3
3
3
3
1
3
3
3
3
59
3
VTFF
1
27
3
47
3
3
81O
3
81R
3
81U
3
3
3
3
59NL
3
Device
Number
Function
25 Synchrocheck
27/27X Bus/Line Undervoltage
32 Sensitive Directional Power
32FP Forward Power
32N Wattmetric zero-sequence directional
46 Negative Sequence Time Overcurrent
47 Negative Sequence Voltage
48 Blocked Rotor
49 Thermal Image - overload protection
50 BF Breaker Failure
50PH/PL Phase Instantaneous Overcurrent (High/Low)
50N Neutral Instantaneous Overcurrent
50G Ground Instantaneous Overcurrent
50SG Sensitive Ground Instantaneous Overcurrent
50IG Isolated Ground Instantaneous Overcurrent
51N Neutral Time Overcurrent
51G Ground Time Overcurrent
51SG Sensitive Ground Time Overcurrent
51PH/V Voltage Restraint Phase Time Overcurrent
51PL/V
59/59X Bus/Line Overvoltage
59NH/NL Neutral Overvoltage - High/Low
67P Phase Directional Overcurrent
67N Neutral Directional Overcurrent
67G Ground Directional Overcurrent
67SG Sensitive Ground Directional Overcurrent
79 Autorecloser
81 U/O Under/Over Frequency Broken Conductor
Detection
N/A Load Encroachment
81R Frequency Rate of Change
VTFF VT Fuse Failure Detection
ANSI Device Numbers & Functions
These records are stored in non volatile
memory. Therefore, there is no need
for internal battery monitoring or
maintenance.
Trip circuit monitoring
complete supervision circuits for breaker
trip and closing coils and circuits. These
supervision inputs monitor both the
battery voltage level and the continuity of
the trip and/or closing circuits, applying
current through those circuits and
to apply this feature it is necessary to
choose I/O board 1 option 2.
Communications
three ports that operate independently.
Redundant ports are available for high
reliability applications:
Available protocols for rear port 1 and 2
are ModBus RTU, IEC 103 and serial DNP
3.0.
The third port is located in a removable
communications card. This plug-and-
play card can be easily changed in the
future as new standards arrive to the
market, thus providing a migration path
to the customer.
The protocol available for the third port
is DNP 3.0 over TCP/IP, UDP/IP, ModBus
ő
Graphic 16 x 40 or text 4 x 20 LCD display
ő
Fluorescent backlight to improve visibility
ő
Multicolor programmable LEDs with label panel
ő
ő
Key control for easy navigation
ő
Ergonomic programmable keys
ő
Electrically isolated front USB communication port
User Interface
Functional Block Diagram
