Packaging
Introduction
For transport, the different parts of the apparatus are divided- up between
several cases :
S Interrupting chambers + (corona rings chambers).
S Columns + (corona rings, electrical connections ...).
S Operating devices : each operating device is wrapped in a protective bag.
S Frames if the latter is supplied by ALSTOM Grid.
S The SF
6
bottle(s) or - in particular instances - SF
6
bottle(s) and CF
4
bottle(s).
S Marshalling cubicle.
S Assembly products (grease, oil, etc.) used for installation.
S Capacitors (if the apparatus is equipped with these).
Characteristics of
packaging cases
The table below gives the characteristics of the circuit- breaker components
packaging cases depending on the apparatus :
Packaging case type Qty
Length
cm
Width
cm
Height
cm
Gross weight
kg
Interrupting chambers
x3
1 513 181 136
Columns
(2 insulators)
1 503 188 108
Columns
(3 insulators)
1 532 191 105
Columns
(4 insulators)
1 627 191 105
Frame
(H = 2503 mm)
1 308 96 96
Frame
(H = 3377 mm)
1 396 96 96
Frame
(H = 4877 mm)
1 546 96 96
Operating device
1 318 103 144
SF
6
gas
*
(SF
6
+CF
4
)
gas
mixture
SF
6
gas
*
CF
4
gas
*
Marshalling cubicle
1 131 76 172 284
Necessities (products)
for assembly
1 60 60 70 37
Capacitors *
1 266 141 124
* Depending of the apparatus
NOTE
: the values in the above table are given as an indication so
that an appropriate means of lifting can be envisaged.
