Introduction
The new Spacemaker 18" Built-In Dishwasher has a compact size,
allowing the unit to fit in areas as small as 18 inches (45.72 cm) wide,
22 inches (55.88 cm) long, and 34 inches (86.36 cm) high. It is
compact in size, yet still delivers the performance of larger units. With
a low power usage, this product model meets ENERGY STAR
®
guidelines for energy efficiency.
The Spacemaker 18" Built-In Dishwasher has two wash levels, a
POTS & PANS cycle, HEAVY WASH cycle, NORMAL WASH cycle,
LIGHT WASH cycle, CHINA CRYSTAL cycle, RINSE ONLY cycle, and a
PLATE WARMER (HEATED DRY ON) option.
Electrical
Rating 120 Volts, 60 Hz ±10%
Separate Circuit 4.5 to 5.5 Amps
Motor (HP) 1/5
Motor (Amps) 1 ±10%
Heater Wattage – Wash/Dry 465 ±10%
Total Amps (Load Rated) 5 ±10%
Component Resistance (OHMS)
Timer Motor 1460 ±10%
Heating Element 31 ±5%
Pump Motor Windings
Drain
Wash (Blue to Red)
27 ±10%
47 ±10%
Run Windings – Main
(Blue to Black)
22 ±10%
Water Valve Solenoid 1140 ±5%
Total Amps (Load Rated) 5 ±10%
Water Supply
Suggested Minimum
Incoming Water Temperature
120 °F to 150 °F
(49 °C to 66 °C)
Sump Water Temperature
With Outer Door In Place
145 °F ±5 °F
(63 °C ±3 °C)
Water Charge 2.54 to 3.27 Quarts
(2.4 to 3.1 Liters)
Pressure (PSI) 20 Min./120 Max.
Connection (NPT) 3/8 In. (0.95 cm)
Consumption (Total) 4.7 to 6.1 Gallons
(17.8 to 23.1 Liters)
Water Valve Flow Rate
(GPM)
1.8 ±14%
(6.81 LPM ±14%)
Water Circulation Rate (GPM) 10 ±10%
(37.85 LPM ±10%)
Water Fill Time (Seconds) 30 (±1)
Specifications
