– 24 –
4. Label and disconnect the 2 terminals to the
motor wire connector.
9. Reverse the above procedure to install.
8. Remove and save the 2 screws, lock-
washers, mounting bracket, and nut plate
from the drain pump.
Mounting Bracket
Caution: The clamp is easily damaged during
removal and should not be reused. Replace the
old clamp with a new universal clamp (part
number: WH1X2036).
6. Remove the clamp from the sump
interconnect hose.
7. Remove the drain pump from the sump
interconnect hose.
5. Remove the 2 bolts, lock-washer, and nuts.
Motor Pump Assembly
The motor pump assembly is located under the
tub behind the sump assembly. This dishwasher
model uses a capacitor start induction motor. The
motor rotates clockwise (as viewed from the
terminal end) and draws approximately 1 amp
(±10%) at 120 VAC (±10%).
Removal and Replacement
1. Disconnect power.
2. Carefully pull the dishwasher out far enough
from its installation to access the drain pump
from the rear of the dishwasher.
3. Label and disconnect the 2 terminals to the
capacitor.
Nut Plate
2 Screws
2 Lock-washers
Capacitor
Interconnect
Hose
Clamp
To Next Page
