MA-014 - TRANSFIX DGA 500 User Guide – Rev 1.1 13-Oct-15 Page 14 of 28
6.1.1.4 Peripheral Scheduler
An information notice lists all peripheral connections as shown in Figure 6—6. If the
peripheral scheduler is enabled, all analogue inputs are listed with corresponding null
values. The product has analogue inputs AIn1 to AIn6, but corresponding values for these
appear after peripheral(s) are connected. By default, a newly shipped product has no
connected peripherals, but a configured installation may have a load sensor connected.
or
Figure 6—6: Peripheral scheduler
6.1.2 Manual Measurements
6.1.2.1 Start a Manual Measurement
Use the blue Start button to initiate a manual measurement on the main tank. The timer
automatically counts down from 10 seconds and then indicates the start of a manual
measurement as shown in Figure 6—7.
Figure 6—7: Start a manual measurement
6.1.2.2 Stop a Measurement
Use the red Stop button to abort an active measurement. After any remaining oil in the
headspace drains, the product returns to Standby as shown in Figure 6—8.
Figure 6—8: Stop a measurement
PERIPHERAL SCHEDULER
STANDBY
>>> OK <<<
MAIN
Analn0 0000.0uuu
Analn1 0000.0uuu
Analn2 0000.0uuu
MAIN
>>> OK <<<
MAIN
MEASUREMENT IN
10 s
2015-04-02 11:21:00
MAIN
MEASUREMENT STARTED
2015-07-30 11:21:10
MAIN
>>> OK <<<
2015-04-02 11:45:00
OIL DRAINING
2015-04-02 12:00:00
STANDBY
