MA-014 - TRANSFIX DGA 500 User Guide – Rev 1.1 13-Oct-15 Page 8 of 28
4 DESIGN CRITERIA
The product is designed to meet the following type tests as listed in Table 4—1:
Table 4—1: Type tests
Category
Standard
Class/Level
Test
EMC Emissions –
EN 61326-1:2006
CISPR 11
A
Radiated & Conducted Emissions
FCC Part 15
A
Radiated & Conducted Emissions
EN 61000-3-2
A
Harmonic Current Emissions
Limits
EMC Immunity –
EN 61326-1:2006
EN 61000-4-2
IV
Electrostatic Discharge
EN 61000-4-3
III
Electromagnetic Field Immunity
EN 61000-4-4
III
Electrical Fast Transients
EN 61000-4-5
III
Surge Immunity
EN 61000-4-6
III
Conducted RF Immunity
EN 61000-4-8
IV & V
Magnetic Field Immunity
IEC 61000-4-9
X
Pulsed Magnetic Field Immunity
IEC 61000-4-10
X
Damped Oscillatory Magnetic
Field Immunity
EN 61000-4-11
III
Voltage Dips & Interruptions
IEC 61000-4-12
X 2.5 kV & 1kV
Oscillatory Wave
IEC 61000-4-18
X
Damped Oscillatory Wave
EN 61000-3-3
Pst 10 min, Plt 120 min
Voltage fluctuations & flicker
EN 60255-5
5 kV, 2 kV & 500 V DC
Impulse, Dielectric & Insulation
resistance testing
Environmental
IEC 60068-2-1
−40 °C
Cold
IEC 60068-2-2
55 °C
Dry Heat
IEC 60068-2-6
10 – 150 Hz, 0.5 g operation
10 – 150 Hz, 0.5 g endurance
Vibration
IEC 60068-2-30
55 °C, 95% RH
Damp Heat
EN 60529
IP55
Degree of Protection
Safety
IEC 61010-1
2010
EN 61010-1
2010
