GE Multilin L60 Line Phase Comparison System 5-107
5 SETTINGS 5.5 GROUPED ELEMENTS
5
5.5.3 PHASE COMPARISON ELEMENTS
a) MAIN MENU
PATH: SETTINGS ÖØ GROUPED ELEMENTS Ö PHASE COMPARISON ELEMENTS
b) 87PC SCHEME
PATH: SETTINGS ÖØ GROUPED ELEMENTS Ö SETTING GROUP 1(6) Ö PHASE COMPARISON ELEMENTS Ö 87PC SCHEME
 PHASE COMPARISON
 ELEMENTS
 87PC SCHEME

See page 5–107.
MESSAGE
 ADVANCED
 FAULT DETECTORS
See page 5–115.
MESSAGE
 CHARGE CURRENT
 COMPENSATION
See page 5–121.
MESSAGE
 OPEN BREAKER
 ECHO
See page 5–123.
 87PC SCHEME

87PC FUNCTION:
Disabled
Range: Disabled, Enabled
MESSAGE
87PC SCHEME SELECT:
2TL-TR-SPC-2FC
Range: 2TL-TR-SPC-2FC, 2TL-BL-SPC-2FC,
2TL-TR-DPC-3FC, etc.
MESSAGE
87PC BLOCK:
Off
Range: FlexLogic™ operand
MESSAGE
87PC SIGNAL SOURCE:
One Source Current
Range: One Source Current, Two Sources Current
MESSAGE
87PC SIGNAL:
Mixed I_2-K*I_1
Range: Mixed I_2–K*I_1, 3I_0
MESSAGE
87PC MIXED SIGNAL K:
0.20
Range: 0.00 to 0.25 in steps of 0.01
MESSAGE
87PC MIXED SIGNAL
REF ANGLE: 0°
Range: 0 to 359° in steps of 1
MESSAGE
87PC FDL PICKUP:
0.50 pu
Range: 0.02 to 15.00 pu in steps of 0.01
MESSAGE
87PC FDL AUX:
Off
Range: FlexLogic™ operand
MESSAGE
87PC FDH PICKUP:
0.75 pu
Range: 0.05 to 15.00 pu in steps of 0.01
MESSAGE
87PC FDH AUX:
Off
Range: FlexLogic™ operand
MESSAGE
87PC FDH SUPV:
Off
Range: FlexLogic™ operand
MESSAGE
87PC CH1 ASYMMETRY:
0.0 ms
Range: –5.0 to 5.0 ms in steps of 0.1
MESSAGE
87PC CH2 ASYMMETRY:
0.0 ms
Range: –5.0 to 5.0 ms in steps of 0.1
MESSAGE
87PC CH1 DELAY:
0.0 ms
Range: 0.0 to 30.0 ms in steps of 0.1
