GE UR series

6-14 L60 Line Phase Comparison System GE Multilin
6.3 METERING 6 ACTUAL VALUES
6
The metered phase current values are displayed in this menu. The "SRC 1" text will be replaced by whatever name was
programmed by the user for the associated source (see SETTINGS ÖØ SYSTEM SETUP ÖØ SIGNAL SOURCES).
c) GROUND CURRENT METERING
PATH: ACTUAL VALUES ÖØ METERING Ö SOURCE SRC 1 ÖØ GROUND CURRENT
The metered ground current values are displayed in this menu. The "SRC 1" text will be replaced by whatever name was
programmed by the user for the associated source (see SETTINGS ÖØ SYSTEM SETUP ÖØ SIGNAL SOURCES).
d) PHASE VOLTAGE METERING
PATH: ACTUAL VALUES ÖØ METERING Ö SOURCE SRC 1 Ö PHASE VOLTAGE
MESSAGE
SRC 1 NEG SEQ I2:
0.000 A 0.0°
 GROUND CURRENT
 SRC 1
SRC 1 RMS Ig:
0.000 A
MESSAGE
SRC 1 PHASOR Ig:
0.000 A 0.0°
MESSAGE
SRC 1 PHASOR Igd:
0.000 A 0.0°
 PHASE VOLTAGE
 SRC 1
SRC 1 RMS Vag:
0.00 V
MESSAGE
SRC 1 RMS Vbg:
0.00 V
MESSAGE
SRC 1 RMS Vcg:
0.00 V
MESSAGE
SRC 1 PHASOR Vag:
0.000 V 0.0°
MESSAGE
SRC 1 PHASOR Vbg:
0.000 V 0.0°
MESSAGE
SRC 1 PHASOR Vcg:
0.000 V 0.0°
MESSAGE
SRC 1 RMS Vab:
0.00 V
MESSAGE
SRC 1 RMS Vbc:
0.00 V
MESSAGE
SRC 1 RMS Vca:
0.00 V
MESSAGE
SRC 1 PHASOR Vab:
0.000 V 0.0°
MESSAGE
SRC 1 PHASOR Vbc:
0.000 V 0.0°
MESSAGE
SRC 1 PHASOR Vca:
0.000 V 0.0°
MESSAGE
SRC 1 ZERO SEQ V0:
0.000 V 0.0°
