6 ACTUAL VALUES 6.3 METERING
6
The metered phase voltage values are displayed in this menu. The "SRC 1" text will be replaced by whatever name was
programmed by the user for the associated source (see SETTINGS ÖØ SYSTEM SETUP ÖØ SIGNAL SOURCES).
e) AUXILIARY VOLTAGE METERING
PATH: ACTUAL VALUES ÖØ METERING Ö SOURCE SRC 1 ÖØ AUXILIARY VOLTAGE
The metered auxiliary voltage values are displayed in this menu. The "SRC 1" text will be replaced by whatever name was
programmed by the user for the associated source (see SETTINGS ÖØ SYSTEM SETUP ÖØ SIGNAL SOURCES).
f) POWER METERING
PATH: ACTUAL VALUES ÖØ METERING Ö SOURCE SRC 1 ÖØ POWER
MESSAGE
SRC 1 POS SEQ V1:
0.000 V 0.0°
MESSAGE
SRC 1 NEG SEQ V2:
0.000 V 0.0°
 AUXILIARY VOLTAGE
 SRC 1
SRC 1 RMS Vx:
0.00 V
MESSAGE
SRC 1 PHASOR Vx:
0.000 V 0.0°
 POWER
 SRC 1
SRC 1 REAL POWER
3φ: 0.000 W
MESSAGE
SRC 1 REAL POWER
φa: 0.000 W
MESSAGE
SRC 1 REAL POWER
φb: 0.000 W
MESSAGE
SRC 1 REAL POWER
φc: 0.000 W
MESSAGE
SRC 1 REACTIVE PWR
3φ: 0.000 var
MESSAGE
SRC 1 REACTIVE PWR
φa: 0.000 var
MESSAGE
SRC 1 REACTIVE PWR
φb: 0.000 var
MESSAGE
SRC 1 REACTIVE PWR
φc: 0.000 var
MESSAGE
SRC 1 APPARENT PWR
3φ: 0.000 VA
MESSAGE
SRC 1 APPARENT PWR
φa: 0.000 VA
MESSAGE
SRC 1 APPARENT PWR
φb: 0.000 VA
MESSAGE
SRC 1 APPARENT PWR
φc: 0.000 VA
MESSAGE
SRC 1 POWER FACTOR
3φ: 1.000
