1D84 Frequency for Source 3 --- Hz --- F003 0
1D86 Frequency for Source 4 --- Hz --- F003 0
1D88 Frequency for Source 5 --- Hz --- F003 0
1D8A Frequency for Source 6 --- Hz --- F003 0
Breaker flashover (read/write setting) (2 modules)
21A6 Breaker flashover 1 function 0 to 1 --- 1 F102 0 (Disabled)
21A7 Breaker flashover 1 side 1 source 0 to 5 --- 1 F167 0 (SRC 1)
21A8 Breaker flashover 1 side 2 source 0 to 6 --- 1 F211 0 (None)
21A9 Breaker flashover 1 status closed A 0 to 65535 --- 1 F300 0
21AA Breaker flashover 1 status closed B 0 to 65535 --- 1 F300 0
21AB Breaker flashover 1 status closed C 0 to 65535 --- 1 F300 0
21AC Breaker flashover 1 voltage pickup level 0 to 1.5 pu 0.001 F001 850
21AD Breaker flashover 1 voltage difference pickup level 0 to 100000 V 1 F060 1000
21AF Breaker flashover 1 current pickup level 0 to 1.5 pu 0.001 F001 600
21B0 Breaker flashover 1 pickup delay 0 to 65.535 s 0.001 F001 100
21B1 Breaker flashover 1 supervision phase A 0 to 65535 --- 1 F300 0
21B2 Breaker flashover 1 supervision phase B 0 to 65535 --- 1 F300 0
21B3 Breaker flashover 1 supervision phase C 0 to 65535 --- 1 F300 0
21B4 Breaker flashover 1 block 0 to 65535 --- 1 F300 0
21B5 Breaker flashover 1 events 0 to 1 --- 1 F102 0 (Disabled)
21B6 Breaker flashover 1 target 0 to 2 --- 1 F109 0 (Self-Reset)
21B7 Reserved (4 items) --- --- --- F001 0
21BB ...Repeated for breaker flashover 2 0 to 99999999 kA
2
-cyc 1 F060 0
Breaker Arcing Current Actuals (Read Only Non-Volatile) (2 modules)
21E0 Breaker 1 Arcing Current Phase A 0 to 99999999 kA
2
-cyc 1 F060 0
21E2 Breaker 1 Arcing Current Phase B 0 to 99999999 kA
2
-cyc 1 F060 0
21E4 Breaker 1 Arcing Current Phase C 0 to 99999999 kA
2
-cyc 1 F060 0
21E6 Breaker 1 Operating Time Phase A 0 to 65535 ms 1 F001 0
21E7 Breaker 1 Operating Time Phase B 0 to 65535 ms 1 F001 0
21E8 Breaker 1 Operating Time Phase C 0 to 65535 ms 1 F001 0
21E9 Breaker 1 Operating Time 0 to 65535 ms 1 F001 0
21EA ...Repeated for Breaker Arcing Current 2
Breaker Arcing Current Commands (Read/Write Command) (2 modules)
2224 Breaker 1 Arcing Current Clear Command 0 to 1 --- 1 F126 0 (No)
2225 Breaker 2 Arcing Current Clear Command 0 to 1 --- 1 F126 0 (No)
Passwords Unauthorized Access (Read/Write Command)
2230 Reset Unauthorized Access 0 to 1 --- 1 F126 0 (No)
Source Current THD (Read Only) (4 modules)
22A0 Source 1 Ia THD 0 to 100 % 0.1 F001 0
22A1 Source 1 Ib THD 0 to 100 % 0.1 F001 0
22A2 Source 1 Ic THD 0 to 100 % 0.1 F001 0
22A3 Source 1 In THD 0 to 100 % 0.1 F001 0
22A4 ...Repeated for Source 2
22A8 ...Repeated for Source 3
22AC ...Repeated for Source 4
Fault Location (Read Only) (5 modules)
2340 Fault 1 Prefault Phase A Current Magnitude 0 to 999999.999 A 0.001 F060 0
2342 Fault 1 Prefault Phase A Current Angle -359.9 to 0 degrees 0.1 F002 0
2343 Fault 1 Prefault Phase B Current Magnitude 0 to 999999.999 A 0.001 F060 0
2345 Fault 1 Prefault Phase B Current Angle -359.9 to 0 degrees 0.1 F002 0
2346 Fault 1 Prefault Phase C Current Magnitude 0 to 999999.999 A 0.001 F060 0
2348 Fault 1 Prefault Phase C Current Angle -359.9 to 0 degrees 0.1 F002 0
2349 Fault 1 Prefault Phase A Voltage Magnitude 0 to 999999.999 V 0.001 F060 0
234B Fault 1 Prefault Phase A Voltage Angle -359.9 to 0 degrees 0.1 F002 0
Table B–9: MODBUS MEMORY MAP (Sheet 6 of 55)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
