GE UR series

GE Multilin L60 Line Phase Comparison System B-21
APPENDIX B B.4 MEMORY MAPPING
B
41D0 Oscillography Analog Channel n (16 items) 0 to 65535 --- 1 F600 0
4200 Oscillography Digital Channel n (63 items) 0 to 65535 --- 1 F300 0
Trip and Alarm LEDs (Read/Write Setting)
4260 Trip LED Input FlexLogic Operand 0 to 65535 --- 1 F300 0
4261 Alarm LED Input FlexLogic Operand 0 to 65535 --- 1 F300 0
User Programmable LEDs (Read/Write Setting) (48 modules)
4280 FlexLogic™ Operand to Activate LED 0 to 65535 --- 1 F300 0
4281 User LED type (latched or self-resetting) 0 to 1 --- 1 F127 1 (Self-Reset)
4282 ...Repeated for User-Programmable LED 2
4284 ...Repeated for User-Programmable LED 3
4286 ...Repeated for User-Programmable LED 4
4288 ...Repeated for User-Programmable LED 5
428A ...Repeated for User-Programmable LED 6
428C ...Repeated for User-Programmable LED 7
428E ...Repeated for User-Programmable LED 8
4290 ...Repeated for User-Programmable LED 9
4292 ...Repeated for User-Programmable LED 10
4294 ...Repeated for User-Programmable LED 11
4296 ...Repeated for User-Programmable LED 12
4298 ...Repeated for User-Programmable LED 13
429A ...Repeated for User-Programmable LED 14
429C ...Repeated for User-Programmable LED 15
429E ...Repeated for User-Programmable LED 16
42A0 ...Repeated for User-Programmable LED 17
42A2 ...Repeated for User-Programmable LED 18
42A4 ...Repeated for User-Programmable LED 19
42A6 ...Repeated for User-Programmable LED 20
42A8 ...Repeated for User-Programmable LED 21
42AA ...Repeated for User-Programmable LED 22
42AC ...Repeated for User-Programmable LED 23
42AE ...Repeated for User-Programmable LED 24
42B0 ...Repeated for User-Programmable LED 25
42B2 ...Repeated for User-Programmable LED 26
42B4 ...Repeated for User-Programmable LED 27
42B6 ...Repeated for User-Programmable LED 28
42B8 ...Repeated for User-Programmable LED 29
42BA ...Repeated for User-Programmable LED 30
42BC ...Repeated for User-Programmable LED 31
42BE ...Repeated for User-Programmable LED 32
42C0 ...Repeated for User-Programmable LED 33
42C2 ...Repeated for User-Programmable LED 34
42C4 ...Repeated for User-Programmable LED 35
42C6 ...Repeated for User-Programmable LED 36
42C8 ...Repeated for User-Programmable LED 37
42CA ...Repeated for User-Programmable LED 38
42CC ...Repeated for User-Programmable LED 39
42CE ...Repeated for User-Programmable LED 40
42D0 ...Repeated for User-Programmable LED 41
42D2 ...Repeated for User-Programmable LED 42
42D4 ...Repeated for User-Programmable LED 43
42D6 ...Repeated for User-Programmable LED 44
42D8 ...Repeated for User-Programmable LED 45
42DA ...Repeated for User-Programmable LED 46
42DC ...Repeated for User-Programmable LED 47
Table B–9: MODBUS MEMORY MAP (Sheet 13 of 55)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
