B.4 MEMORY MAPPING APPENDIX B
B
Ethernet switch (Read/Write Setting)
4148 Ethernet switch IP address 0 to 4294967295 --- 1 F003 3232235778
414A Ethernet switch Modbus IP port number 1 to 65535 --- 1 F001 502
414B Ethernet switch Port 1 Events 0 to 1 --- 1 F102 0 (Disabled)
414C Ethernet switch Port 2 Events 0 to 1 --- 1 F102 0 (Disabled)
414D Ethernet switch Port 3 Events 0 to 1 --- 1 F102 0 (Disabled)
414E Ethernet switch Port 4 Events 0 to 1 --- 1 F102 0 (Disabled)
414F Ethernet switch Port 5 Events 0 to 1 --- 1 F102 0 (Disabled)
4150 Ethernet switch Port 6 Events 0 to 1 --- 1 F102 0 (Disabled)
Ethernet switch (Read Only Actual Values)
4151 Ethernet switch MAC address --- --- 1 F072 0
4154 Ethernet switch Port 1 Status 0 to 2 --- 1 F134 0 (Fail)
4155 Ethernet switch Port 2 Status 0 to 2 --- 1 F134 0 (Fail)
4156 Ethernet switch Port 3 Status 0 to 2 --- 1 F134 0 (Fail)
4157 Ethernet switch Port 4 Status 0 to 2 --- 1 F134 0 (Fail)
4158 Ethernet switch Port 5 Status 0 to 2 --- 1 F134 0 (Fail)
4159 Ethernet switch Port 6 Status 0 to 2 --- 1 F134 0 (Fail)
415A Switch Firmware Version 0.00 to 99.99 --- 0.01 F001 0
Simple Network Time Protocol (Read/Write Setting)
4168 Simple Network Time Protocol (SNTP) function 0 to 1 --- 1 F102 0 (Disabled)
4169 Simple Network Time Protocol (SNTP) server IP address 0 to 4294967295 --- 1 F003 0
416B Simple Network Time Protocol (SNTP) UDP port number 1 to 65535 --- 1 F001 123
Data Logger Commands (Read/Write Command)
4170 Data Logger Clear 0 to 1 --- 1 F126 0 (No)
Data Logger (Read/Write Setting)
4181 Data Logger Channel Settings (16 items) --- --- --- F600 0
4191 Data Logger Mode 0 to 1 --- 1 F260 0 (continuous)
4192 Data Logger Trigger 0 to 65535 --- 1 F300 0
4193 Data Logger Rate 15 to 3600000 ms 1 F003 60000
Clock (Read/Write Command)
41A0 Real Time Clock Set Time 0 to 235959 --- 1 F050 0
Clock (Read/Write Setting)
41A2 SR Date Format 0 to 4294967295 --- 1 F051 0
41A4 SR Time Format 0 to 4294967295 --- 1 F052 0
41A6 IRIG-B Signal Type 0 to 2 --- 1 F114 0 (None)
41A7 Clock Events Enable / Disable 0 to 1 --- 1 F102 0 (Disabled)
41A8 Time Zone Offset from UTC –24 to 24 hours 0.5 F002 0
41A9 Daylight Savings Time (DST) Function 0 to 1 --- 1 F102 0 (Disabled)
41AA Daylight Savings Time (DST) Start Month 0 to 11 --- 1 F237 0 (January)
41AB Daylight Savings Time (DST) Start Day 0 to 6 --- 1 F238 0 (Sunday)
41AC Daylight Savings Time (DST) Start Day Instance 0 to 4 --- 1 F239 0 (First)
41AD Daylight Savings Time (DST) Start Hour 0 to 23 --- 1 F001 2
41AE Daylight Savings Time (DST) Stop Month 0 to 11 --- 1 F237 0 (January)
41AF Daylight Savings Time (DST) Stop Day 0 to 6 --- 1 F238 0 (Sunday)
41B0 Daylight Savings Time (DST) Stop Day Instance 0 to 4 --- 1 F239 0 (First)
41B1 Daylight Savings Time (DST) Stop Hour 0 to 23 --- 1 F001 2
Fault Report Commands (Read/Write Command)
41B2 Fault Reports Clear Data Command 0 to 1 --- 1 F126 0 (No)
Oscillography (Read/Write Setting)
41C0 Oscillography Number of Records 1 to 64 --- 1 F001 15
41C1 Oscillography Trigger Mode 0 to 1 --- 1 F118 0 (Auto. Overwrite)
41C2 Oscillography Trigger Position 0 to 100 % 1 F001 50
41C3 Oscillography Trigger Source 0 to 65535 --- 1 F300 0
41C4 Oscillography AC Input Waveforms 0 to 4 --- 1 F183 2 (16 samples/cycle)
Table B–9: MODBUS MEMORY MAP (Sheet 12 of 55)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
