GE UR series

B-24 L60 Line Phase Comparison System GE Multilin
B.4 MEMORY MAPPING APPENDIX B
B
4D00 ...Repeated for User-Definable Display 9
4D20 ...Repeated for User-Definable Display 10
4D40 ...Repeated for User-Definable Display 11
4D60 ...Repeated for User-Definable Display 12
4D80 ...Repeated for User-Definable Display 13
4DA0 ...Repeated for User-Definable Display 14
4DC0 ...Repeated for User-Definable Display 15
4DE0 ...Repeated for User-Definable Display 16
User Programmable Pushbuttons (Read/Write Setting) (12 modules)
4E00 User Programmable Pushbutton 1 Function 0 to 2 --- 1 F109 2 (Disabled)
4E01 User Programmable Pushbutton 1 Top Line --- --- --- F202 (none)
4E0B User Programmable Pushbutton 1 On Text --- --- --- F202 (none)
4E15 User Programmable Pushbutton 1 Off Text --- --- --- F202 (none)
4E1F User Programmable Pushbutton 1 Drop-Out Time 0 to 60 s 0.05 F001 0
4E20 User Programmable Pushbutton 1 Target 0 to 2 --- 1 F109 0 (Self-reset)
4E21 User Programmable Pushbutton 1 Events 0 to 1 --- 1 F102 0 (Disabled)
4E22 User Programmable Pushbutton 1 LED Operand 0 to 65535 --- 1 F300 0
4E23 User Programmable Pushbutton 1 Autoreset Delay 0 to 600 s 0.05 F001 0
4E24 User Programmable Pushbutton 1 Autoreset Function 0 to 1 --- 1 F102 0 (Disabled)
4E25 User Programmable Pushbutton 1 Local Lock 0 to 65535 --- 1 F300 0
4E26 User Programmable Pushbutton 1 Message Priority 0 to 2 --- 1 F220 0 (Disabled)
4E27 User Programmable Pushbutton 1 Remote Lock 0 to 65535 --- 1 F300 0
4E28 User Programmable Pushbutton 1 Reset 0 to 65535 --- 1 F300 0
4E29 User Programmable Pushbutton 1 Set 0 to 65535 --- 1 F300 0
4E2A ...Repeated for User Programmable Pushbutton 2
4E54 ...Repeated for User Programmable Pushbutton 3
4E7E ...Repeated for User Programmable Pushbutton 4
4EA8 ...Repeated for User Programmable Pushbutton 5
4ED2 ...Repeated for User Programmable Pushbutton 6
4EFC ...Repeated for User Programmable Pushbutton 7
4F26 ...Repeated for User Programmable Pushbutton 8
4F50 ...Repeated for User Programmable Pushbutton 9
4F7A ...Repeated for User Programmable Pushbutton 10
4FA4 ...Repeated for User Programmable Pushbutton 11
4FCE ...Repeated for User Programmable Pushbutton 12
Flexlogic (Read/Write Setting)
5000 FlexLogic™ Entry (512 items) 0 to 65535 --- 1 F300 16384
RTD Inputs (Read/Write Setting) (48 modules)
5400 RTD Input 1 Function 0 to 1 --- 1 F102 0 (Disabled)
5401 RTD Input 1 ID --- --- --- F205 “RTD Ip 1“
5407 RTD Input 1 Type 0 to 3 --- 1 F174 0 (100 ohm Platinum)
5413 ...Repeated for RTD Input 2
5426 ...Repeated for RTD Input 3
5439 ...Repeated for RTD Input 4
544C ...Repeated for RTD Input 5
545F ...Repeated for RTD Input 6
5472 ...Repeated for RTD Input 7
5485 ...Repeated for RTD Input 8
5498 ...Repeated for RTD Input 9
54AB ...Repeated for RTD Input 10
54BE ...Repeated for RTD Input 11
54D1 ...Repeated for RTD Input 12
54E4 ...Repeated for RTD Input 13
54F7 ...Repeated for RTD Input 14
Table B–9: MODBUS MEMORY MAP (Sheet 16 of 55)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
