GE UR series

GE Multilin L60 Line Phase Comparison System B-25
APPENDIX B B.4 MEMORY MAPPING
B
550A ...Repeated for RTD Input 15
551D ...Repeated for RTD Input 16
5530 ...Repeated for RTD Input 17
5543 ...Repeated for RTD Input 18
5556 ...Repeated for RTD Input 19
5569 ...Repeated for RTD Input 20
557C ...Repeated for RTD Input 21
558F ...Repeated for RTD Input 22
55A2 ...Repeated for RTD Input 23
55B5 ...Repeated for RTD Input 24
55C8 ...Repeated for RTD Input 25
55DB ...Repeated for RTD Input 26
55EE ...Repeated for RTD Input 27
5601 ...Repeated for RTD Input 28
5614 ...Repeated for RTD Input 29
5627 ...Repeated for RTD Input 30
563A ...Repeated for RTD Input 31
564D ...Repeated for RTD Input 32
5660 ...Repeated for RTD Input 33
5673 ...Repeated for RTD Input 34
5686 ...Repeated for RTD Input 35
5699 ...Repeated for RTD Input 36
56AC ...Repeated for RTD Input 37
56BF ...Repeated for RTD Input 38
56D2 ...Repeated for RTD Input 39
56E5 ...Repeated for RTD Input 40
56F8 ...Repeated for RTD Input 41
570B ...Repeated for RTD Input 42
571E ...Repeated for RTD Input 43
5731 ...Repeated for RTD Input 44
5744 ...Repeated for RTD Input 45
5757 ...Repeated for RTD Input 46
576A ...Repeated for RTD Input 47
577D ...Repeated for RTD Input 48
Flexlogic Timers (Read/Write Setting) (32 modules)
5800 FlexLogic™ Timer 1 Type 0 to 2 --- 1 F129 0 (millisecond)
5801 FlexLogic™ Timer 1 Pickup Delay 0 to 60000 --- 1 F001 0
5802 FlexLogic™ Timer 1 Dropout Delay 0 to 60000 --- 1 F001 0
5803 Reserved (5 items) 0 to 65535 --- 1 F001 0
5808 ...Repeated for FlexLogic™ Timer 2
5810 ...Repeated for FlexLogic™ Timer 3
5818 ...Repeated for FlexLogic™ Timer 4
5820 ...Repeated for FlexLogic™ Timer 5
5828 ...Repeated for FlexLogic™ Timer 6
5830 ...Repeated for FlexLogic™ Timer 7
5838 ...Repeated for FlexLogic™ Timer 8
5840 ...Repeated for FlexLogic™ Timer 9
5848 ...Repeated for FlexLogic™ Timer 10
5850 ...Repeated for FlexLogic™ Timer 11
5858 ...Repeated for FlexLogic™ Timer 12
5860 ...Repeated for FlexLogic™ Timer 13
5868 ...Repeated for FlexLogic™ Timer 14
5870 ...Repeated for FlexLogic™ Timer 15
5878 ...Repeated for FlexLogic™ Timer 16
Table B–9: MODBUS MEMORY MAP (Sheet 17 of 55)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
