B-28 L60 Line Phase Comparison System GE Multilin
B.4 MEMORY MAPPING APPENDIX B
B
5D20 ...Repeated for Ground Time Overcurrent 3
5D30 ...Repeated for Ground Time Overcurrent 4
5D40 ...Repeated for Ground Time Overcurrent 5
5D50 ...Repeated for Ground Time Overcurrent 6
Ground Instantaneous Overcurrent (Read/Write Grouped Setting) (12 modules)
5E00 Ground Instantaneous Overcurrent 1 Signal Source 0 to 5 --- 1 F167 0 (SRC 1)
5E01 Ground Instantaneous Overcurrent 1 Function 0 to 1 --- 1 F102 0 (Disabled)
5E02 Ground Instantaneous Overcurrent 1 Pickup 0 to 30 pu 0.001 F001 1000
5E03 Ground Instantaneous Overcurrent 1 Delay 0 to 600 s 0.01 F001 0
5E04 Ground Instantaneous Overcurrent 1 Reset Delay 0 to 600 s 0.01 F001 0
5E05 Ground Instantaneous Overcurrent 1 Block 0 to 65535 --- 1 F300 0
5E06 Ground Instantaneous Overcurrent 1 Target 0 to 2 --- 1 F109 0 (Self-reset)
5E07 Ground Instantaneous Overcurrent 1 Events 0 to 1 --- 1 F102 0 (Disabled)
5E08 Reserved (8 items) 0 to 1 --- 1 F001 0
5E10 ...Repeated for Ground Instantaneous Overcurrent 2
5E20 ...Repeated for Ground Instantaneous Overcurrent 3
5E30 ...Repeated for Ground Instantaneous Overcurrent 4
5E40 ...Repeated for Ground Instantaneous Overcurrent 5
5E50 ...Repeated for Ground Instantaneous Overcurrent 6
5E60 ...Repeated for Ground Instantaneous Overcurrent 7
5E70 ...Repeated for Ground Instantaneous Overcurrent 8
5E80 ...Repeated for Ground Instantaneous Overcurrent 9
5E90 ...Repeated for Ground Instantaneous Overcurrent 10
5EA0 ...Repeated for Ground Instantaneous Overcurrent 11
5EB0 ...Repeated for Ground Instantaneous Overcurrent 12
Setting Groups (Read/Write Setting)
5F80 Setting Group for Modbus Comms (0 means group 1) 0 to 5 --- 1 F001 0
5F81 Setting Groups Block 0 to 65535 --- 1 F300 0
5F82 FlexLogic to Activate Groups 2 through 6 (5 items) 0 to 65535 --- 1 F300 0
5F89 Setting Group Function 0 to 1 --- 1 F102 0 (Disabled)
5F8A Setting Group Events 0 to 1 --- 1 F102 0 (Disabled)
Setting Groups (Read Only)
5F8B Current Setting Group 0 to 5 --- 1 F001 0
Setting Group Names (Read/Write Setting)
5F8C Setting Group 1 Name --- --- --- F203 (none)
5F94 Setting Group 2 Name --- --- --- F203 (none)
5F9C Setting Group 3 Name --- --- --- F203 (none)
5FA4 Setting Group 4 Name --- --- --- F203 (none)
5FAC Setting Group 5 Name --- --- --- F203 (none)
5FB4 Setting Group 6 Name --- --- --- F203 (none)
Wattmetric ground fault settings (read/write grouped, 2 modules)
6050 Wattmetric ground fault 1 function 0 to 1 --- 1 F102 0 (Disabled)
6051 Wattmetric ground fault 1 source 0 to 5 --- 1 F167 0 (SRC 1)
6052 Wattmetric ground fault 1 voltage 0 to 1 --- 1 F234 0 (Calculated VN)
6053 Wattmetric ground fault 1 overvoltage pickup 0.02 to 3.00 pu 0.01 F001 20
6054 Wattmetric ground fault 1 current 0 to 1 --- 1 F235 (Calculated IN)
6055 Wattmetric ground fault 1 overcurrent pickup 0.002 to 30.000 pu 0.001 F001 60
6056 Wattmetric ground fault 1 overcurrent pickup delay 0 to 600 s 0.01 F001 20
6057 Wattmetric ground fault 1 power pickup 0.001 to 1.2 pu 0.001 F001 100
6058 Wattmetric ground fault 1 ECA 0 to 360 ° Lag 1 F001 0
6059 Wattmetric ground fault 1 power pickup delay 0 to 600 s 0.01 F001 20
605A Wattmetric ground fault 1 curve 0 to 5 --- 1 F236 0 (Definite Time)
605B Wattmetric ground fault 1 multiplier 0.01 to 2 s 0.01 F001 100
605C Wattmetric ground fault 1 block 0 to 65535 --- 1 F300 0
Table B–9: MODBUS MEMORY MAP (Sheet 20 of 55)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
To Next Page
