GE UR series

GE Multilin L60 Line Phase Comparison System B-29
APPENDIX B B.4 MEMORY MAPPING
B
605D Wattmetric ground fault 1 target 0 to 2 --- 1 F109 0 (Self-reset)
605E Wattmetric ground fault 1 events 0 to 1 --- 1 F102 0 (Disabled)
605F Wattmetric ground fault 1 reference power 0.001 to 1.2 pu 0.001 F001 500
6060 Reserved --- --- --- --- ---
6061 ...Repeated for wattmetric ground fault 2
Wattmetric ground fault actual values (read only)
6072 Wattmetric ground fault 1 operating power 0.000 to 1000000.000 W 0.001 F060 0
6074 Wattmetric ground fault 2 operating power 0.000 to 1000000.000 W 0.001 F060 0
Phase comparison: negative-sequence voltage fault detection settings (read/write, grouped)
6080 Negative-sequence voltage fault detector function 0 to 1 --- 1 F102 0 (Disabled)
6081 Negative-sequence voltage fault detector impedance 0 to 100 % .01 F001 100
6082 Negative-sequence voltage fault detector low pickup 0.005 to 3.000 pu 0.001 F001 10
6083 Negative-sequence voltage fault detector high pickup 0.005 to 3.000 pu 0.001 F001 50
6084 Negative-sequence voltage fault detector block 0 to 65535 --- 1 F300 0
6085 Negative-sequence voltage fault detector target 0 to 2 --- 1 F109 0 (Self-reset)
6086 Negative-sequence voltage fault detector events 0 to 1 --- 1 F102 0 (Disabled)
Phase comparison: rate of change of negative-sequence current settings (read/write, grouped)
6088 Negative-sequence current rate of change function 0 to 1 --- 1 F102 0 (Disabled)
6089 Negative-sequence current rate of change low pickup 0.01 to 5.00 pu 0.01 F001 10
608A Negative-sequence current rate of change low seal-in 0 to 10.000 s 0.001 F001 600
608B Negative-sequence current rate of change high pickup 0.01 to 5.00 pu 0.01 F001 50
608C Negative-sequence current rate of change high seal-in 0 to 10.000 s 0.001 F001 200
608D Negative-sequence current rate of change supervision 0 to 65535 --- 1 F300 0
608E Negative-sequence current rate of change block 0 to 65535 --- 1 F300 0
608F Negative-sequence current rate of change target 0 to 2 --- 1 F109 0 (Self-reset)
6090 Negative-sequence current rate of change events 0 to 1 --- 1 F102 0 (Disabled)
Phase comparison: rate of change of positive-sequence current settings (read/write, grouped)
6091 Positive-sequence current rate of change function 0 to 1 --- 1 F102 0 (Disabled)
6092 Positive-sequence current rate of change low pickup 0.01 to 5.00 pu 0.01 F001 10
6093 Positive-sequence current rate of change low seal-in 0 to 10.000 s 0.001 F001 600
6094 Positive-sequence current rate of change high pickup 0.01 to 5.00 pu 0.01 F001 50
6095 Positive-sequence current rate of change high seal-in 0 to 10.000 s 0.001 F001 200
6096 Positive-sequence current rate of change supervision 0 to 65535 --- 1 F300 0
6097 Positive-sequence current rate of change block 0 to 65535 --- 1 F300 0
6098 Positive-sequence current rate of change target 0 to 2 --- 1 F109 0 (Self-reset)
6099 Positive-sequence current rate of change events 0 to 1 --- 1 F102 0 (Disabled)
Phase comparison negative-sequence current fault detector (read/write grouped settings)
60A0 Negative-sequence current fault detector function 0 to 1 --- 1 F102 0 (Disabled)
60A1 Negative-sequence current fault detector low pickup 0.02 to 5 pu 0.01 F001 10
60A2 Negative-sequence current fault detector high pickup 0.05 to 15 pu 0.01 F001 50
60A3 Negative-sequence current fault detector block 0 to 65535 --- 1 F300 0
60A4 Negative-sequence current fault detector target 0 to 2 --- 1 F109 0 (Self-reset)
60A5 Negative-sequence current fault detector events 0 to 1 --- 1 F102 0 (Disabled)
Phase comparison positive-sequence current fault detector (read/write grouped settings)
60A8 Positive-sequence current fault detector function 0 to 1 --- 1 F102 0 (Disabled)
60A9 Positive-sequence current fault detector low pickup 0.02 to 5 pu 0.01 F001 50
60AA Positive-sequence current fault detector high pickup 0.05 to 15 pu 0.01 F001 75
60AB Positive-sequence current fault detector block 0 to 65535 --- 1 F300 0
60AC Positive-sequence current fault detector target 0 to 2 --- 1 F109 0 (Self-reset)
60AD Positive-sequence current fault detector events 0 to 1 --- 1 F102 0 (Disabled)
Phase Comparison Open Breaker Keying (Read/Write Grouped Setting)
60E0 Open Breaker Keying 0 to 1 --- 1 F102 0 (Disabled)
60E1 Breaker 1 Auxiliary Contact 0 to 65535 --- 1 F300 0
60E2 Breaker 1 Supervision Element 0 to 65535 --- 1 F300 0
Table B–9: MODBUS MEMORY MAP (Sheet 21 of 55)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
