GE UR series

GE Multilin L60 Line Phase Comparison System B-33
APPENDIX B B.4 MEMORY MAPPING
B
6816 Breaker Phase B Open 0 to 65535 --- 1 F300 0
6817 Breaker Phase C Open 0 to 65535 --- 1 F300 0
6818 Trip Events 0 to 1 --- 1 F102 0 (Disabled)
6819 Reverse Fault Operand 0 to 65535 --- 1 F300 0
681A Trip Delay On Evolving Faults 0 to 65.535 s 0.001 F001 0
681B Reserved (5 items) 0 to 1 --- 1 F001 0
Open Pole Detect (Read/Write Setting)
6820 Open Pole Function 0 to 1 --- 1 F102 0 (Disabled)
6821 Open Pole Block 0 to 65535 --- 1 F300 0
6822 Open Pole Voltage Supervision 0 to 1 --- 1 F102 0 (Disabled)
6823 Open Pole Current Pickup 0 to 30 pu 0.001 F001 50
6824 Open Pole Target 0 to 2 --- 1 F109 0 (Self-reset)
6825 Open Pole Events 0 to 1 --- 1 F102 0 (Disabled)
6826 Open Pole Line XC0 300 to 9999.9 ohms 0.1 F003 99999
6828 Open Pole Line XC1 300 to 9999.9 ohms 0.1 F003 99999
682A Open Pole Remote Current Pickup 0 to 30 pu 0.001 F001 50
682B Reserved (5 items) 0 to 1 --- 1 F001 0
Autoreclose 1P 3P (Read/Write Setting)
6890 Autoreclose Mode 0 to 3 --- 1 F080 0 (1 & 3 Pole)
6891 Autoreclose Maximum Number of Shots 1 to 4 --- 1 F001 2
6892 Autoreclose Block Breaker 1 0 to 65535 --- 1 F300 0
6893 Autoreclose Close Time Breaker 1 0 to 655.35 s 0.01 F001 10
6894 Autoreclose Breaker Manual Close 0 to 65535 --- 1 F300 0
6895 Autoreclose Function 0 to 1 --- 1 F102 0 (Disabled)
6896 Autoreclose Block Time Manual Close 0 to 655.35 s 0.01 F001 1000
6897 Autoreclose 1P Initiate 0 to 65535 --- 1 F300 0
6898 Autoreclose 3P Initiate 0 to 65535 --- 1 F300 0
6899 Autoreclose 3P TD Initiate 0 to 65535 --- 1 F300 0
689A Autoreclose Multi-Phase Fault 0 to 65535 --- 1 F300 0
689B Autoreclose Breaker 1 Pole Open 0 to 65535 --- 1 F300 0
689C Autoreclose Breaker 3 Pole Open 0 to 65535 --- 1 F300 0
689D Autoreclose 3-Pole Dead Time 1 0 to 655.35 s 0.01 F001 50
689E Autoreclose 3-Pole Dead Time 2 0 to 655.35 s 0.01 F001 120
689F Autoreclose Extend Dead T1 0 to 65535 --- 1 F300 0
68A0 Autoreclose Dead T1 Extension 0 to 655.35 s 0.01 F001 50
68A1 Autoreclose Reset 0 to 65535 --- 1 F300 0
68A2 Autoreclose Reset Time 0 to 655.35 s 0.01 F001 6000
68A3 Autoreclose Breaker Closed 0 to 65535 --- 1 F300 0
68A4 Autoreclose Block 0 to 65535 --- 1 F300 0
68A5 Autoreclose Pause 0 to 65535 --- 1 F300 0
68A6 Autoreclose Incomplete Sequence Time 0 to 655.35 s 0.01 F001 500
68A7 Autoreclose Block Breaker 2 0 to 65535 --- 1 F300 0
68A8 Autoreclose Close Time Breaker 2 0 to 655.35 s 0.01 F001 10
68A9 Autoreclose Transfer 1 to 2 0 to 1 --- 1 F126 0 (No)
68AA Autoreclose Transfer 2 to 1 0 to 1 --- 1 F126 0 (No)
68AB Autoreclose Breaker 1 Fail Option 0 to 1 --- 1 F081 0 (Continue)
68AC Autoreclose Breaker 2 Fail Option 0 to 1 --- 1 F081 0 (Continue)
68AD Autoreclose 1P Dead Time 0 to 655.35 s 0.01 F001 100
68AE Autoreclose Breaker Sequence 0 to 4 --- 1 F082 3 (1 - 2)
68AF Autoreclose Transfer Time 0 to 655.35 s 0.01 F001 400
68B0 Autoreclose Event 0 to 1 --- 1 F102 0 (Disabled)
68B1 Autoreclose 3P Dead Time 3 0 to 655.35 s 0.01 F001 200
68B2 Autoreclose 3P Dead Time 4 0 to 655.35 s 0.01 F001 400
68B3 Autoreclose Bus Fault Initiate 0 to 65535 s 0.01 F300 0
Table B–9: MODBUS MEMORY MAP (Sheet 25 of 55)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
